Black panel-mount bracket with two blue USB 3.0 Type-A ports and a 50cm 20-pin header cable

LORDWORLD

LORDWORLD USB 3.0 Panel Mount 20-Pin Header Dual Port 50cm Cable

SKU CH-2Z6Y-V7GTV

A 50 cm panel-mount cable converts one motherboard 20-pin header into two USB 3.0 Type-A ports with screw-hole mounting

  • Adds two front-panel USB 3.0 ports from a single 20-pin header
  • 50 cm cable reaches most mid-tower front panels
  • Two screw holes enable secure panel mounting
  • USB 3.0 specification compliant for 5 Gbps throughput
  • Single-piece moulded construction resists cable strain

Panel-Mount USB 3.0 Adapter for Front Panels

This adapter converts a motherboard 20-pin USB 3.0 header into two panel-mount Type-A ports. It is intended for builders adding front-panel USB 3.0 connectivity to a custom chassis or replacing a damaged front-panel connector. The 50 cm cable length suits typical desktop layouts.

Check Header Layout and Panel Cut-Out

Verify that the motherboard provides a 19-pin or 20-pin USB 3.0 header matching the plug on this cable. Ensure the chassis front panel has a rectangular cut-out with two screw holes spaced for the included mounting flange. No driver installation is required on modern operating systems.

Two Ports From One Header

The single 20-pin connector splits to two USB 3.0 Type-A sockets, doubling the available front-panel ports without occupying additional headers. The stackable flange design allows secure screw mounting to metal or plastic panels. Molded strain relief on the cable ends reduces wear from repeated plugging.

Highlights

  • Adds two front-panel USB 3.0 ports from a single 20-pin header
  • 50 cm cable reaches most mid-tower front panels
  • Two screw holes enable secure panel mounting
  • USB 3.0 specification compliant for 5 Gbps throughput
  • Single-piece moulded construction resists cable strain

Specifications

BrandLORDWORLD

Questions about this item

What comes in the box and do I need any extra mounting hardware?

The package includes the panel-mount cable with two USB 3.0 Type-A female ports and a single 20-pin header plug. Two screw holes are moulded into the female end for panel mounting; screws are not supplied.

The title mentions both 19-pin and 20-pin headers — which one does this cable actually use?

The connector that plugs into the motherboard is a 20-pin USB 3.0 header. The 19-pin reference in the listing title is an error; this cable only fits a 20-pin socket.

What does the 5 Gbps rating mean when the cable is installed in a PC?

The link runs at USB 3.0 SuperSpeed, so each port can transfer up to 5 Gbps when connected to a compatible motherboard header and used with USB 3.0 devices.
