Green PCB expansion card with three blue USB-A ports and two red USB-C ports on a metal bracket

LORDWORLD

LORDWORLD PCIe USB 3.1 Gen2 Card 3×Type-A 2×Type-C ASM3142 VL822

SKU CH-T40T-ADEM0

Adds three Type-A and two Type-C ports at 10 Gbps via a PCIe slot with ASM3142 and VL822 controllers

  • 10 Gbps transfer speed backed by ASM3142 and VL822 dual chipset
  • No external power required thanks to built-in self-powered IC
  • Five rear ports: three Type-A and two Type-C connectors
  • Driver-free on Windows 10, macOS 10.8.2+ and Linux
  • Backward compatible with USB 2.0 and 1.1 devices

PCIe USB 3.1 Gen2 expansion card

This PCIe expansion card adds three Type-A USB 3.0 ports and two Type-C USB 3.1 Gen2 ports to a desktop system. It uses the ASM3142 and VL822 dual-chipset design to deliver up to 10Gbps data rates across the USB 3.1 Gen2 interface. The card targets users who need more high-speed USB connections for external drives or peripherals.

Single-slot PCIe installation with self-powered IC

The adapter fits a standard PCI Express slot and requires no external power cable thanks to its built-in self-powered IC. It provides 5V power to attached devices while drawing from the slot itself. Backwards compatibility covers USB 3.0 Super-Speed at 5Gbps, USB 2.0 Hi-Speed at 480Mbps and USB 1.1 Low-Speed at 1.5Mbps.

Sustained 10Gbps throughput via Multiple INs

Under continuous load the ASM3142 controller uses its Multiple INs feature to keep the 10Gbps bus saturated rather than falling back to burst speeds. Driver-free operation applies to Windows 10, Mac OS 10.8.2 and above, and Linux; Windows 7 still needs a driver install. Not suited for builds that lack a free PCIe slot or need internal header connections.

Highlights

  • 10 Gbps transfer speed backed by ASM3142 and VL822 dual chipset
  • No external power required thanks to built-in self-powered IC
  • Five rear ports: three Type-A and two Type-C connectors
  • Driver-free on Windows 10, macOS 10.8.2+ and Linux
  • Backward compatible with USB 2.0 and 1.1 devices

Specifications

BrandLORDWORLD

Questions about this item

Does the 10Gbps bandwidth hold up when all five ports are active?

The ASM3142 chipset uses Multiple INs to keep the 10Gbps rate fully utilised across the bus, so each port can reach that speed even under simultaneous load.

How much heat or noise does the card produce during all-day operation?

No external power connector is needed because a self-powered IC is built in, keeping power draw and heat low enough for passive cooling in a standard case.

What slot and operating system does my motherboard need for this card to work?

A free PCIe slot plus Windows 7, 8, 10, Mac OS 10.8.2 or newer, or Linux; Windows 10, Mac and Linux run driver-free, while Windows 7 requires a driver install.
