Right-angle NEMA 6-20P plug, black nylon body, rotatable 12 positions, brass terminals

LORDWORLD

LORDWORLD Nema 6-20P Right Angle Rotatable AC Plug 12 Direction 15A 250V

SKU CH-N5VH-J4PNQ

A right-angle NEMA 6-20P plug rotates to 12 positions and accepts 18 to 12 AWG cords for 15 A 250 V DIY wiring

  • Right-angle design keeps cords close to the wall
  • Rotates to 12 positions for flexible cable routing
  • Rated 15 A at 250 V for heavy-duty appliances
  • Screw-lock terminals accept 18 to 12 AWG cords
  • UL-certified nylon housing with 94V-0 flame rating

Right-angle NEMA 6-20P plug

This UL-certified male AC plug uses a right-angle body that rotates to twelve positions. It accepts 15 A at 250 V and suits DIY rewiring of power cords in home or workshop settings. The three poles are brass and the pins are copper.

Build and connector details

A screw-lock terminal design secures conductors without soldering. The housing is nylon rated to vertical flame class 94V-0. Compatible cord sizes include SJT 18, 16, 14 and AWG 12. The rotatable body eases routing in tight outlets or behind equipment.

Replaces fixed-angle 6-20P plugs

Use this when a straight or single-orientation plug blocks adjacent sockets or strains the cable. The twelve-angle adjustment removes the need to rewire just to change cable exit direction. Not suited for circuits requiring 20 A rating or non-NEMA 6-20 configurations.

Highlights

  • Right-angle design keeps cords close to the wall
  • Rotates to 12 positions for flexible cable routing
  • Rated 15 A at 250 V for heavy-duty appliances
  • Screw-lock terminals accept 18 to 12 AWG cords
  • UL-certified nylon housing with 94V-0 flame rating

Specifications

BrandLORDWORLD

Questions about this item

What does the NEMA 6-20P rating allow this plug to handle?

The NEMA 6-20P configuration supports 15 A at 250 V AC for North American power circuits.

What cable gauges fit the screw terminals on this right-angle plug?

The screw-lock terminals accept SJT 18, 16, 14 and AWG 12 conductors.

How do you set one of the 12 rotation angles before wiring the plug?

Loosen the housing screw, turn the body to the desired orientation, tighten the screw, then terminate the wires.
