Yellow nylon angled plug with three brass blades and strain reliefs

LORDWORLD

LORDWORLD Nema 5-50P 50A 125V Angle Plug 1.06in

SKU CH-YWMK-817A5

A 50 A 125 V NEMA 5-50P angle plug with nylon UL 94-V0 housing, brass terminals for 12–6 AWG cable and strain reliefs supporting up to 1.06 in OD

  • Heavy-duty 50 A 125 V plug powers welders and dryers safely
  • UL 94-V0 nylon shell resists heat and meets RoHS REACH standards
  • Accepts cable diameters up to 1.06 in for 12–6 AWG conductors
  • Insulated nylon housing shields live parts on the hand-held side
  • Brass terminals simplify wiring for 12 AWG to 6 AWG copper wires

Nema 5-50P 50A Angle Plug

This rewireable AC power plug carries a 50A 125V rating and a Nema 5-50P configuration. It is built for welders, dryers and similar high-draw equipment that need a straight-blade grounding connection. The nylon shell meets UL 94-V0 and complies with ROHS REACH. Pure copper blades and brass terminals deliver reliable conductivity in industrial and commercial settings.

Cable Compatibility and Strain Relief

The plug accepts cord outer diameters up to 1.06 inches and supports 12AWG through 6AWG three-conductor cables including SJT, STO, SJTO, SO, ST, SRD and SVO types. Two strain-relief inserts are supplied: use both for 12AWG cord, the single 10AWG insert for 10AWG cord, and the metal pressure plate alone for larger cables. An internal dust shield keeps terminals free of contaminants during assembly and use.

Sustained Load Behaviour

Brass terminals and copper blades resist heat rise when the plug carries continuous current near its 50A rating. The insulated nylon housing shields exposed metal parts on the hand-held side, reducing the risk of accidental contact during prolonged operation. Terminals accept copper wire from 12AWG to 6AWG and clamp tightly to maintain low resistance over extended duty cycles. The design is not suited for applications requiring a locking or twist-lock interface.

Highlights

  • Heavy-duty 50 A 125 V plug powers welders and dryers safely
  • UL 94-V0 nylon shell resists heat and meets RoHS REACH standards
  • Accepts cable diameters up to 1.06 in for 12–6 AWG conductors
  • Insulated nylon housing shields live parts on the hand-held side
  • Brass terminals simplify wiring for 12 AWG to 6 AWG copper wires

Specifications

BrandLORDWORLD

Questions about this item

How many amps can the LORDWORLD 5-50P plug handle continuously?

The plug is rated for 50 amps at 125 volts, matching the NEMA 5-50P standard for welders and dryers.

Does the nylon housing limit heat rise during all-day welding?

The UL 94-V0 nylon shell and brass terminals resist heat rise, while the internal dust shield keeps contacts clean under sustained loads.

What cable sizes and strain reliefs do I need before wiring this plug?

Use 12 AWG to 6 AWG three-conductor cord up to 1.06 in. OD; 12 AWG needs both strain reliefs, 10 AWG uses the 10 AWG relief, larger cables use the metal clamp only.
