Black nylon angled plug with three brass blades and PVC strain relief

LORDWORLD

LORDWORLD NEMA 14-30P 30A 125/250V Angle Plug

SKU CH-R0SW-KY6CT

A 30 A, 125/250 V angle plug with UL 94-V0 nylon housing and brass terminals for 12 AWG to 6 AWG cable up to 1.06 in OD

  • Rewireable 30 A 125/250 V angle plug for dryer and range connections
  • UL 94-V0 nylon housing shields live parts and meets ROHS REACH standards
  • Brass terminals accept 12 to 6 AWG copper wire for secure installation
  • Supports cable outer diameter up to 1.06 inches with two strain-relief options
  • Industrial straight-blade design resists heat rise and keeps terminals dust-free

NEMA 14-30P 30A angle plug for dryers and ranges

This rewireable AC power plug fits NEMA 14-30 receptacles rated 30 amps at 125/250 volts. It is built for DIY installation on dryer and range cords. The angled body eases routing in tight laundry or kitchen spaces.

Nylon UL 94-V0 housing with brass terminals

The shell uses pure nylon rated UL 94-V0 and meets ROHS and REACH. Brass terminals accept copper conductors from 12 AWG to 6 AWG. Two strain-relief inserts are supplied; the 12 AWG cord uses both inserts together while 10 AWG uses only the 10 AWG insert. Cables larger than 10 AWG rely on the metal pressure clamp.

Cord diameter limit 1.06 inches

The plug accommodates cord outer diameters up to 1.06 inches and suits SJT, STJW, STO, SJTO, SO, ST, SRD, SVO and similar three-conductor types. An internal dust shield keeps terminals free of contaminants. Builders needing four-wire configurations or higher amperage ratings cannot use this device.

Highlights

  • Rewireable 30 A 125/250 V angle plug for dryer and range connections
  • UL 94-V0 nylon housing shields live parts and meets ROHS REACH standards
  • Brass terminals accept 12 to 6 AWG copper wire for secure installation
  • Supports cable outer diameter up to 1.06 inches with two strain-relief options
  • Industrial straight-blade design resists heat rise and keeps terminals dust-free

Specifications

BrandLORDWORLD

Questions about this item

What is the maximum continuous current this NEMA 14-30P plug is rated to carry?

The plug is rated for 30 amps at 125/250 volts, which is the continuous current limit for dryer and range connections.

How much does the nylon housing resist heat rise during all-day operation?

The industrial-strength brass blades and contacts are designed to resist heat rise, while the UL 94-V0 nylon shell insulates exposed metal parts on the hand-held side.

Which wire gauges and cord types must I already have to wire this plug correctly?

It accepts copper conductors from 12 AWG to 6 AWG, three conductors, and supports cord types such as SJT, STO, SJTO, SO, ST, SRD and SVO with an outside diameter up to 1.06 inches.
