Slim silver DVD burner with slot-load face, 12.7 mm thick

Lite-On

Lite-On DS-8ABSH-01 slim DVD burner SATA 12.7 mm

SKU CH-Q71Q-2EZDH MPN DS-8ABSH-01

A slim 12.7 mm SATA DVD burner with slot loading that writes DVD±R at 8X, dual-layer at 6X and CD-R at 24X

  • TypeSlim DVD Burner
  • DVD-ROM Access Time150ms
  • CD-ROM Access Time130ms
  • DVD+R8X
  • DVD+RW8X
  • DVD-R8X
  • 8X DVD±R write speed for quick disc creation
  • 24X CD-R write speed for fast audio or data burning
  • 130ms CD-ROM access for responsive reading
  • 150ms DVD-ROM access for smooth playback
  • 7 mm slim slot-load form factor fits compact bays

Slim 12.7 mm DVD burner

The Lite-On DS-8ABSH-01 is a new slim DVD burner designed for laptops or compact desktops with a 12.7 mm drive bay. It connects via a SATA interface and uses a slot-load mechanism. Supported operating systems include Windows 8, 7, XP, Linux and Mac OS.

8X DVD write speeds with dual-layer support

The drive writes DVD+R and DVD-R at 8X and DVD+RW at 8X. DVD-RW writes at 6X. Dual-layer DVD+R DL and DVD-R DL are supported at 6X. DVD-RAM writes at 5X. CD-R and CD-RW both reach 24X. Read speeds are 8X for DVD-ROM and 24X for CD-ROM. Access times are 150 ms for DVD and 130 ms for CD.

Fits slim SATA bays and frees external ports

The 12.7 mm form factor fits standard slim internal bays without an external enclosure. A SATA data and power connection is required inside the chassis. The slot-load design eliminates a protruding tray. Internal mounting keeps USB ports free for other peripherals.

Highlights

  • 8X DVD±R write speed for quick disc creation
  • 24X CD-R write speed for fast audio or data burning
  • 130ms CD-ROM access for responsive reading
  • 150ms DVD-ROM access for smooth playback
  • 7 mm slim slot-load form factor fits compact bays

Specifications

BrandLITE-ON
ModelDS-8ABSH-01
TypeSlim DVD Burner
DVD-ROM Access Time150ms
CD-ROM Access Time130ms
DVD+R8X
DVD+RW8X
DVD-R8X
DVD-RW6X
CD-R24X
CD-RW24X
DVD+R DL6X
DVD-R DL6X
DVD-RAM5X
DVD-ROM8X
CD-ROM24X
Form FactorSlim 12.7 mm
Load TypeSlot
InterfaceSATA
Operating Systems SupportedMicrosoft Windows 8/7 32 or 64 bit verion; or Windows XP; Linux and Mac OS supported
FeaturesSATA interface, 12.7mm height and high efficient power saving modes for notebook computer use.
DVD+R / DVD+RW / DVD-R / DVD-RW / DVD+R DL/ DVD-R DL/ DVD-RAM / CD-R/ CD-RW writer
Support Double Layer DVD+/- R Recording Function
SMART-BURN avoiding Buffer Under Run error, Automatically adjusting writing strategy & running OPC to provide the best burning quality
SMART-X function adjusts CD-DA / VCD / DVD data extraction to a fastest allowable speed according to both data request rate from host and disk quality
Support Fixed Packet, Variable Packet, TAO, SAO, DAO, Random Access time, Inc
System RequirementsPentium 4 1.3GHz or faster CPU, 512 MB DRAM Required
HDD must have up to 10GB free space for DVD authoring processes
Shipping weight0.14 kg
Package size187 × 149 × 39 mm

Questions about this item

Will the 12.7 mm slim SATA drive fit in the same bay as my older 12.7 mm IDE optical drive?

The physical height matches at 12.7 mm, but the interface changes from IDE to SATA, so you need a SATA data cable and a SATA power connector from your system.

How can I verify the drive reads and writes at its rated speeds after installation?

Burn a DVD+R at 8X and a CD-R at 24X, then check the write-speed graph in your burning software; read a pressed DVD-ROM at 8X and a CD-ROM at 24X to confirm the 150 ms and 130 ms access times.

Does the box include a SATA data cable, mounting screws or a bezel, or must I source them separately?

The package contains only the bare DS-8ABSH-01 drive; you must supply a SATA data cable, a SATA power lead and any chassis screws or front bezel your laptop or enclosure requires.
