10.1 inch IPS monitor with dustproof front panel, HDMI VGA DVI AV inputs, matte black finish

Lilliput

Lilliput FA1014-NP/C 10.1" IPS 1280x800 350cd/m² camera accessory

SKU CH-ARSD-WR2FN MPN FA1014-NP/C

A 10.1" IPS camera monitor with 1280x800 resolution, 350cd/m² brightness and HDMI, VGA, AV, DVI inputs for DSLR and cinema cameras

  • TypeCamera Display Screen
  • 1" IPS panel gives twice the viewing area of a 7" screen
  • 1280×800 native resolution supports up to 1920×1080 input
  • 350 cd/m² brightness with 800:1 contrast for clear outdoor monitoring
  • HDMI, VGA, AV and DVI inputs suit DSLR and cinema cameras
  • Integrated dustproof front panel protects the display in field use

10.1-inch IPS camera display

The Lilliput FA1014-NP/C is a non-touch 10.1-inch IPS monitor built for camera operators who need a larger viewing area than standard on-camera screens. It accepts HDMI, DVI, VGA and AV signals and supports input resolutions up to 1920 x 1080 while displaying a native 1280 x 800 picture. An integrated dustproof front panel protects the screen during outdoor or studio use.

Sustained brightness and viewing stability

Rated at 350 cd/m² with an 800:1 contrast ratio, the panel maintains consistent output during long recording sessions without the dimming seen in smaller screens under continuous load. Lux auto-brightness adjusts backlight levels to ambient light, reducing eye strain and preserving visibility. Wide 170-degree horizontal and vertical viewing angles keep the image accurate for operators positioned off-centre.

DC 7-24V power envelope and connectivity limits

The unit draws 800 mA at up to 10 W across a 7-24 V DC range, so it runs from common camera batteries or mains adapters without a dedicated regulator. A single I/O control port handles external tally or trigger functions, while one built-in speaker provides 1 W audio monitoring. Operating temperature spans 0 to 50 °C, with storage rated from -20 to 60 °C.

Highlights

  • 1" IPS panel gives twice the viewing area of a 7" screen
  • 1280×800 native resolution supports up to 1920×1080 input
  • 350 cd/m² brightness with 800:1 contrast for clear outdoor monitoring
  • HDMI, VGA, AV and DVI inputs suit DSLR and cinema cameras
  • Integrated dustproof front panel protects the display in field use

Specifications

TypeCamera Display Screen

Questions about this item

How much power does the 10.1-inch display draw when running continuously at 350 cd/m² brightness?

The monitor consumes 10 W and draws 800 mA from a DC 7-24 V supply.

Which cables and power source must I already have to connect this monitor to a camera?

You need an HDMI, VGA, DVI or AV cable matching your camera output and a 7-24 V DC power source capable of 800 mA.

Will the 1280×800 IPS panel still show a clear image when mounted beside older 7-inch monitors on a rig?

Yes, the 170° horizontal and vertical viewing angles and 800:1 contrast keep the picture consistent from the same off-axis positions as smaller displays.
