Lenovo ThinkPad P71 Xeon E3-1505M v6 32GB ECC 1TB SSD+HDD Quadro P3000 17.3 laptop
17.3-inch mobile workstation with Xeon E3-1505M v6, 32GB ECC DDR4, 1TB SSD plus 1TB HDD, Quadro P3000 6GB graphics and 4G LTE WWAN
- ColorBlack
- Other FeaturesFingerprint reader, Secure Chip
- Operating SystemWindows 10 Pro
- CPU TypeIntel Xeon
- Processor NameIntel Xeon E3-1505M v6
- Core NameKaby Lake
- Xeon E3-1505M v6 reaches 4.00 GHz turbo for fast compute
- 32 GB DDR4 ECC RAM protects data integrity during heavy workloads
- 3 inch FHD IPS 1920 x 1080 display shows accurate colour
- Quadro P3000 6 GB GPU drives ISV-certified 3D applications
- 1 TB SSD plus 1 TB HDD gives large capacity and quick access
Mobile workstation for certified apps
The ThinkPad P71 is a 17.3 inch mobile workstation built around an Intel Xeon E3-1505M v6 processor and NVIDIA Quadro P3000 graphics. It targets engineers and designers who need ISV-certified stability for professional 3D and rendering applications. The system includes 32GB of DDR4 ECC memory for data integrity and a fingerprint reader for hardware-based security. Windows 10 Pro provides the operating environment out of the box.
Step up from consumer laptops
This configuration replaces consumer-grade notebooks that lack error-correcting memory and professional GPU drivers certified for CAD and simulation software. The jump is worth it when your workflow demands validated driver stacks and ECC protection against silent data corruption during long compute jobs. Integrated 4G LTE WWAN adds connectivity for field work where Wi-Fi is unavailable. The Quadro P3000 6GB GPU handles viewport acceleration for certified applications.
32GB ECC and dual-drive storage
The 32GB DDR4 ECC capacity comfortably handles large assemblies, point-cloud data and multi-application workloads without paging. Combined 1TB M.2 SSD and 1TB hard drive provide fast boot and application load times alongside high-capacity project storage. The 17.3 inch FHD IPS panel at 1920x1080 resolution delivers accurate colour for visual review. Memory headroom runs out when datasets exceed the installed 32GB limit, requiring a platform with higher maximum capacity.
Highlights
- Xeon E3-1505M v6 reaches 4.00 GHz turbo for fast compute
- 32 GB DDR4 ECC RAM protects data integrity during heavy workloads
- 3 inch FHD IPS 1920 x 1080 display shows accurate colour
- Quadro P3000 6 GB GPU drives ISV-certified 3D applications
- 1 TB SSD plus 1 TB HDD gives large capacity and quick access
Specifications
| Brand | Lenovo |
|---|---|
| Series | P71 |
| Model | Thinkpad |
| Part Number | 20HK |
| Color | Black |
| Other Features | Fingerprint reader, Secure Chip |
| Operating System | Windows 10 Pro |
| CPU Type | Intel Xeon |
| Processor Name | Intel Xeon E3-1505M v6 |
| Core Name | Kaby Lake |
| Turbo Frequency | 4.00 GHz |
| Number of Cores | Quad-core Processor |
| CPU L2 Cache | 8 MB |
| CPU L3 Cache | 8 MB |
| Screen Size | 17.3" |
| Touchscreen | Non-Touch Screen |
| Display Type | FHD |
| Resolution | 1920 x 1080 |
| Display Features | In-plane Switching (IPS) Technology |
| GPU/VPU | NVIDIA Quadro P3000 |
| Video Memory | Dedicated 6 GB |
| Graphic Type | Dedicated Card |
| SSD | 1TB |
| HDD | 1TB |
| Memory | 32GB |
| Memory Speed | DDR4 2400 |
| LAN | 10/100/1000Mbps |
| WLAN | 802.11ac Wireless LAN |
| Bluetooth | Bluetooth 4.1 |
| USB | 4 |
| Video Port | 2 x Thunderbolts |
| Docking Connector | 1 |
| Audio Ports | 1 x Headphone/Microphone Combo Jack |
| Audio | Integrated Sound card |
| Speaker | Integrated Stereo Speakers |
| Touchpad | ThinkPad UltraNav |
| Keyboard | Full size with Keyboard light |
| Backlit Keyboard | Backlit |
| Other Input Devices | Yes |
| Webcam | Yes |
| Card Reader | 4-in-1 |
| Style | Standard |
| Type | Workstation |
| Usage | Business |
| AC Adapter/Charger | 230-watt AC Adapter |
| Battery | 8-cell Lithium Ion |
| Dimensions (W x D x H) | 16.38 x 10.85 x 1.3 |
| Weight | 7 - 7.9 lbs. |
Questions about this item
What drive form factors and capacities fit the storage bays of the ThinkPad P71?
The laptop ships with a 256GB M.2 SSD and a 1TB 2.5-inch hard drive, so one M.2 slot and one 2.5-inch bay are available for upgrades.
Which screw or latch secures the bottom cover during RAM or drive installation, and how is it released?
Remove the ten Phillips screws on the base; the cover then lifts off, giving access to both SODIMM slots and the 2.5-inch drive bay.
When should the 32GB DDR4 ECC memory be upgraded, and what module specification is required?
Upgrade when workloads exceed 32GB; use DDR4 2400 MHz ECC SODIMMs to match the installed memory speed and error-correction.
