Black metal box with HDMI and RJ45 ports, four small receiver units and IR cables included

Lenkeng Technology Co,. Ltd

Lenkeng Technology Co,. Ltd LKV314-HDbitT-4.0 1x4 HDMI Splitter Extender 1080P 120m

SKU CH-NTN9-56WMA

Splits one HDMI source to four displays over CAT5e/6 cable up to 120 m at 1080p60 with IR pass-back

Option 4 Way

  • Split one HDMI source to four displays simultaneously
  • Extend 1080p signals up to 120 metres over CAT5e/6 cable
  • IR pass-back at 20 to 60 Hz enables remote control of the source
  • Plug-and-play operation requires no software or configuration
  • Wall-mountable transmitter and receivers simplify permanent installations

1x4 HDMI Splitter Extender

The Lenkeng LKV314-HDbitT-4.0 sends a single HDMI source to four displays over standard network cable. It is built for installers who need identical 1080p images across multiple screens in classrooms, digital-signage walls or meeting rooms. Plug-and-play operation and wall-mount brackets keep setup simple.

Replaces point-to-point HDMI runs

Long copper HDMI cables are limited to short distances and cannot feed four screens from one source without an active distribution amplifier. This kit combines splitting and extension in one system, so the jump is worth it whenever the displays sit farther than a passive cable allows or when four outputs are required from a single player.

120 m reach at 1080p60

Each receiver delivers 1920x1080 at 60 Hz up to 120 metres over CAT5e or CAT6 cable. The 20–60 Hz IR pass-back lets a remote control at any display operate the source device. Bandwidth tops out at 1080p, so 4K or higher refresh rates are not supported.

Highlights

  • Split one HDMI source to four displays simultaneously
  • Extend 1080p signals up to 120 metres over CAT5e/6 cable
  • IR pass-back at 20 to 60 Hz enables remote control of the source
  • Plug-and-play operation requires no software or configuration
  • Wall-mountable transmitter and receivers simplify permanent installations

Specifications

No published specifications for this item yet.

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What cable category and maximum run length does the LKV314-HDbitT-4.0 support for the 1080p signal?

The system works with CAT5, CAT5e or CAT6 network cable and carries 1920x1080@60Hz up to 120 metres or 394 feet per link.

Which power supplies are included and what input voltage do they accept?

Five AC adapters are supplied — one for the transmitter and one for each of the four receivers — each rated for 110~240V input.

How is IR control routed back from the display locations to the source?

Four IR receiver cables plug into the receiver units and one IR blaster cable connects to the transmitter, passing 20~60Hz IR signals back to the source device.
