Small brass flow control valve with 4mm push-to-connect inlet and 1/8 BSPT outlet, silver metal body, screwdriver adjustment slot

Legris

Legris 7060 04 10 Flow Control Valve 4mm 1/8 BSPT 145 psi

SKU CH-WBB7-6MMM7 MPN 7060

Controls flow with a 4 mm push-to-connect inlet and 1/8 BSPT outlet, rated 14.5–145 psi and 158 °F

  • TypeDrain Components
  • MaterialHAWA
  • Precise flow adjustment via screwdriver-actuated control
  • 4 mm push-to-connect inlet for quick tubing installation
  • 1/8 in BSPT outlet threads directly into standard ports
  • Operates reliably from 14.5 to 145 psi
  • Withstands temperatures up to 158 °F

Pneumatic flow control valve

The Legris 7060 04 10 regulates compressed-air flow in a single direction using a screwdriver-adjusted needle. It accepts 4 mm push-to-connect tubing on the inlet and 1/8 in BSPT on the outlet. Maximum working pressure is 145 psi with a pressure range of 14.5 to 145 psi. The valve body rotates 360 degrees for flexible routing.

Installers needing inline speed control

Suits pneumatic circuits that require precise actuator speed adjustment at the cylinder port. Not for systems that need bi-directional metering or electronic proportional control. Builders requiring higher temperature tolerance above 158 °F should select a different valve class.

1/8 in BSPT outlet thread

The outlet port uses a 1/8 in BSPT male thread, so the mating fitting or port must match this exact thread form and size. Verify the counterpart thread before ordering to avoid leaks or assembly issues.

Highlights

  • Precise flow adjustment via screwdriver-actuated control
  • 4 mm push-to-connect inlet for quick tubing installation
  • 1/8 in BSPT outlet threads directly into standard ports
  • Operates reliably from 14.5 to 145 psi
  • Withstands temperatures up to 158 °F

Specifications

TypeDrain Components
MaterialHAWA
BrandLegris
Model7060 04 10

Questions about this item

How much heat does the 145 psi valve generate when running continuously?

The valve operates up to 158 degrees F maximum temperature, so heat output stays within that limit during all-day pneumatic use.

Which fittings must I already have to connect the 4mm push-to-connect inlet and 1/8 BSPT outlet?

You need a 4 mm push-to-connect tube for the inlet and a 1/8 inch BSPT threaded fitting for the outlet.

Will the 360-degree rotation interfere with older 14.5 psi minimum-pressure circuits?

The valve’s pressure range starts at 14.5 psi, so it works with existing low-pressure lines while the full rotation allows flexible routing.
