Silver half-rack metal box with HDMI, VGA, HDBaseT, audio and control ports

Kramer Electronics

Kramer Electronics VP-440X 87-00002090 4K presentation switcher distribution

SKU CH-N4BP-EPQQY MPN 87-00002090

4K presentation switcher with four HDMI inputs, one VGA input, simultaneous HDMI and HDBaseT outputs, analog audio embedding, and RS-232 control

  • VideoMax. Resolution: 4K@60Hz (4:4:4) Max Data Rate: 18Gbps (6Gbp
  • HDMIINPUTS: 4 HDMI: On female HDMI connectors OUTPUTS: 1 HDMI: O
  • Network Interface1 Ethernet: On an RJ-45 female connector
  • USB Port1 USB: On a female USB-A connector for firmware upgrade
  • VGAINPUTS: 1 VGA: On a 15-pin HD connector
  • Analog AduioINPUTS: 5 Stereo Analog Unbalanced Audio: On a 3.5mm mini ja
  • 4K@60Hz 4:4:4 on HDMI for crisp presentations
  • HDBaseT output reaches 70m at 1080p for long runs
  • Four HDMI inputs plus VGA connect many sources
  • Embedded analog audio and microphone simplify cabling
  • 18 Gbps bandwidth handles HDR10 and deep colour

4K Presentation Switcher for Professional AV

The Kramer VP-440X is an 18G 4K presentation switcher and scaler designed for professional AV installations. It provides simultaneous HDMI and HDBaseT outputs with HDCP 1.4 and 2.2 compliance and HDR10 support. The unit accepts four HDMI inputs and one VGA input alongside analog audio and microphone sources.

HDBaseT Range Limits at 4K and 1080p

The HDBaseT 1.0 extension line reaches 40m at 4K@60Hz 4:2:0 and 70m at 1080p@60Hz 24bpp when using Kramer HDBaseT cables. The HDMI output supports 4K@60Hz 4:4:4 at 18Gbps maximum data rate. Analog audio embedding and de-embedding is available on both output paths.

Verify Source Compatibility and Control Needs

Confirm your sources match the listed HDMI and VGA input resolutions before ordering. The switcher includes RS-232 terminals for device control and serial link extension plus an Ethernet port for network management. A USB-A port handles firmware upgrades and a 5V DC 4A power adapter is included.

Highlights

  • 4K@60Hz 4:4:4 on HDMI for crisp presentations
  • HDBaseT output reaches 70m at 1080p for long runs
  • Four HDMI inputs plus VGA connect many sources
  • Embedded analog audio and microphone simplify cabling
  • 18 Gbps bandwidth handles HDR10 and deep colour

Specifications

BrandKramer
ModelVP-440X (87-00002090)
VideoMax. Resolution: 4K@60Hz (4:4:4)
Max Data Rate: 18Gbps (6Gbps per graphic channel)
Standards Compliance: HDCP 1.4 & 2.2. Supports HDR10
Input Resolutions HDMI: 480i/576i, 480p/576p, 720p@60/50Hz, 1080i@60/50Hz, 1080p@60/50Hz, 1080p@24/25/30Hz, 640x480@60/67/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600X900@60Hz RB, 1680x1050@60Hz, 1920x1200@60Hz RB, 2048x1080@24/25/30/50/60Hz, 4K/2K@24/25/30/50/60Hz, 4K/2K(4:2:0)@5
HDMIINPUTS: 4 HDMI: On female HDMI connectors
OUTPUTS: 1 HDMI: On a female HDMI connector
Network Interface1 Ethernet: On an RJ-45 female connector
USB Port1 USB: On a female USB-A connector for firmware upgrade
VGAINPUTS: 1 VGA: On a 15-pin HD connector
Analog AduioINPUTS: 5 Stereo Analog Unbalanced Audio: On a 3.5mm mini jack
OUTPUTS: 1 Stereo Analog Unbalanced Audio: On a 3.5mm mini jack
Other ConnectorINPUTS: 1 Microphone: On a 6.3mm jack
OUTPUTS: 1 HDBaseT: On an RJ-45 connector
PORTS:
1 DATA RS-232: On a 3-pin terminal block for serial link extension
1 CTRL RS-232: On a 3-pin terminal block for device control
6 Contact Closure Switches: On a 7-pin terminal block connector
Power Consumption18-19W
Power Supply5V DC, 4A
SpecificationEXTENSION LINE:
Compliance: HDBaseT 1.0
Up to 40m (130ft): At 4K@60Hz (4:2:0)
Up to 70m (230ft): At full HD (1080p @60Hz 24bpp)
Note: When using Kramer HDBaseT cables
ENCLOSURE:
Cooling: Convection ventilation
Type: Aluminum
Size: 1/2 19"
ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0° to +40°C (32° to 104°FHz)
Storage Temperature: -40° to +70°C (-40° to 158°FHz)
Humidity: 10% to 90%, RHL non-condensing
Feature4 HDMI inputs
Supports up to 4K@60 4:4:4 on the HDMI output
Supports up to 4K@60 4:2:0 on the HDBaseT output
HDBaseT Max. Range: 70m (230ft) at 1080p, 40m (130ft) at 4K@60Hz (4:2:0)
Analog audio and microphone embedding
CEC Support for display ON/OFF
Upscales and downscales to / from all resolutions
Dimensions8.45" x 6.42" x 1.72"
Weight2.40 lbs.
Package ContentIncluded: Power adapter, rubber feet
Shipping weight1.65 kg
Package size351 × 212 × 72 mm

Questions about this item

Should I use the HDMI or the HDBaseT output for a 4K@60Hz 4:4:4 display?

Use the HDMI output; it supports 4K@60Hz 4:4:4. The HDBaseT output is limited to 4K@60Hz 4:2:0.

What does the 18Gbps max data rate mean for my 4K sources?

It allows full 4K@60Hz 4:4:4 and HDR10 pass-through on the HDMI output without chroma subsampling.

How far can I run the HDBaseT link at 4K resolution?

Up to 40m (130ft) at 4K@60Hz 4:2:0 with Kramer HDBaseT cables; 70m (230ft) at 1080p.
