Silver aluminium box with HDMI, RJ45 and mini-jack ports

Kramer Electronics

Kramer Electronics 10-8048901190 1:2 HDBaseT repeater 4K60 4:2:0

SKU CH-ANT6-S7YNW MPN 10-8048901190

Distributes one HDMI signal to two HDBaseT outputs up to 4K 60 Hz 4:2:0 with an HDMI loop output for daisy-chaining

  • Extender & Repeater TypeWired
  • Resolution Support4096 x 2160
  • Network InterfaceUSER INTERFACE: Indicator LEDs: Outputs, inputs, communicati
  • S-VideoVIDEO: Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel
  • Other ConnectorINPUTS: 1 HDMI: On an HDMI female connector OUTPUTS: 2 HDBT:
  • Power ConsumptionConsumption: 5V DC, 1.6A
  • Distributes one HDMI source to two HDBaseT displays
  • Loop HDMI output enables local monitoring or daisy-chaining
  • 4K@60Hz 4:2:0 resolution up to 40 metres
  • 1080p signals reach up to 70 metres over HDBaseT
  • HDCP 1.4 and HDBaseT 1.0 compliant for broad compatibility

1:2 HDBaseT extender distributor

The VM-2HDT takes a single HDMI source and sends it over two RJ-45 HDBaseT outputs for long-reach distribution. It supports video up to 4K@60Hz (4:2:0) 24bpp and passes HDCP 1.4 protected content. An additional HDMI loop output allows a local display or daisy-chaining another unit. The unit is built for professional AV installations needing reliable signal extension.

Aluminium MegaTool enclosure with convection cooling

The aluminium chassis measures 19.00cm x 11.60cm x 2.70cm and weighs 0.5kg, using passive convection ventilation with no fan noise. Front-panel indicator LEDs show output status, input presence, communication link and power at a glance. Twelve DIP switches and an EDID setup button handle configuration without software. A mini-USB port provides RS-232 access for firmware upgrades, while a 3.5mm mini jack and 3-pin terminal block extend IR and RS-232 control signals alongside the video.

Bundled 5.2V DC 4A power supply

The included 5.2V DC 4A power adapter delivers the 5V DC 1.6A the unit requires, so no separate sourcing is needed. This allows immediate deployment in rack or desktop setups. The extender works with any HDBaseT 1.0 compliant receiver such as the TP-580R, reaching 40m at 4K and 70m at 1080p over standard category cable. It does not suit installations needing HDCP 2.2 or full 4:4:4 colour sampling at 4K60.

Highlights

  • Distributes one HDMI source to two HDBaseT displays
  • Loop HDMI output enables local monitoring or daisy-chaining
  • 4K@60Hz 4:2:0 resolution up to 40 metres
  • 1080p signals reach up to 70 metres over HDBaseT
  • HDCP 1.4 and HDBaseT 1.0 compliant for broad compatibility

Specifications

BrandKramer
Extender & Repeater TypeWired
Resolution Support4096 x 2160
Network InterfaceUSER INTERFACE:
Indicator LEDs: Outputs, inputs, communication link and power
Controls: EDID setup button, 12 setup DIP switches
1 RS-232: On a Mini–USB female connector for firmware upgrade
S-VideoVIDEO:
Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution: Up to 4K@60Hz (4:2:0) 24bpp
Standards Compliance: Supports HDCP 1.4 and HDBaseT 1.0
HDMI Support: Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
Other ConnectorINPUTS:
1 HDMI: On an HDMI female connector
OUTPUTS:
2 HDBT: On RJ–45 female connectors
1 Loop HDMI: On an HDMI female connector
PORTS:
1 IR: On a 3.5mm mini jack for IR link extension
1 RS-232: On a 3–pin terminal block for serial link extension
EXTENSION LINE:
Up to 40m (130ft): At 4K@60Hz (4:2:0) (when using Kramer HDBaseT cables)
Up to 70m (230ft): At full HD (1080p @60Hz 36bpp) (when using Kramer HDBaseT cables)
Power ConsumptionConsumption: 5V DC, 1.6A
Power SupplySource: 5.2V DC, 4A
FeatureENCLOSURE:
Size: MegaTool
Type: Aluminum
Cooling: Convection ventilation
ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0° to +40°C (32° to 104°F)
Storage Temperature: –40° to +70°C (–40° to 158°F)
Humidity: 10% to 90%, RHL non–condensing
DimensionsPRODUCT DIMENSIONS
19.00cm x 11.60cm x 2.70cm (7.48" x 4.57" x 1.06" ) W, D, H
SHIPPING DIMENSIONS
34.50cm x 16.50cm x 5.20cm (13.58" x 6.50" x 2.05" ) W, D, H
WeightPRODUCT WEIGHT
0.5kg (1.0lbs) approx.
SHIPPING WEIGHT
1.3kg (2.8lbs) approx.
Package ContentIncluded: Power supply
Shipping weight1.03 kg
Package size376 × 168 × 58 mm

Questions about this item

What resolution does the HDBaseT 1.0 interface cap at in practice?

The HDBaseT 1.0 link supports up to 4K@60Hz 4:2:0 24bpp, with a maximum reach of 40m at that resolution and up to 70m at 1080p.

What rack or surface mounting does the MegaTool aluminium enclosure need?

The unit measures 19.00cm wide, 11.60cm deep and 2.70cm high, weighing 0.5kg, and uses convection ventilation so it requires free airflow around the case.

How is the RS-232 firmware port accessed and what step is often missed?

Firmware upgrades use the Mini-USB female connector; the common mistake is connecting to the 3-pin terminal block RS-232 port instead, which is for control signals only.
