Small white rectangular LED controller with 5.5 by 2.1 mm DC jack and six-pin screw terminals

KEHIPI

KEHIPI C05Z Zigbee 3.0 RGBCCT LED lighting controller

SKU CH-K1YR-JBJX5 MPN C05Z

Zigbee 3.0 controller drives RGBCCT LED strips at up to 15 A across 5 V, 12 V or 24 V and links multiple units for extended range

  • ColorWhite
  • SpecificationsBTF-LIGHTING
  • Dimensions3.0 in x 1.4 in x 0.7 in
  • Package ContentsLED controller, User manual
  • Voice control via Alexa, Google Home and Echo Plus
  • Zigbee 3.0 mesh extends range to 30 m per unit
  • Controls RGBCCT strips with 6 A per channel
  • Auto-sync keeps multiple controllers in step
  • Wide DC 5–24 V input with 15 A total output

Zigbee 3.0 RGBCCT controller

The KEHIPI C05Z is a Zigbee 3.0 controller that drives six-channel RGBCCT LED strips using PWM. It accepts DC input from 5 V to 24 V and delivers up to 6 A per channel with a total limit of 15 A. The unit pairs with Tuya or Smart Life apps and works with Echo Plus, 4th-generation Echo and HomeKit gateways.

Suits app-based whole-home lighting.

Builders who want voice and automation control through Alexa, Google Home or Apple HomeKit will find the Zigbee link reliable. The controller also relays signals to other units up to 30 m away, enabling extended runs. Buyers who need direct RF remote operation should look elsewhere because this model does not support any RF handset.

15 A total output across six channels

The single decisive figure is the 15 A combined current ceiling, which translates to 75 W at 5 V, 180 W at 12 V and 360 W at 24 V. Exceeding this limit will trip the controller, so the LED load must stay within the rated maximum for the chosen supply voltage.

Highlights

  • Voice control via Alexa, Google Home and Echo Plus
  • Zigbee 3.0 mesh extends range to 30 m per unit
  • Controls RGBCCT strips with 6 A per channel
  • Auto-sync keeps multiple controllers in step
  • Wide DC 5–24 V input with 15 A total output

Specifications

BrandBTF-LIGHTING
ModelC05Z
ColorWhite
Part NumberC05Z
SpecificationsBTF-LIGHTING
Dimensions3.0 in x 1.4 in x 0.7 in
Package ContentsLED controller, User manual

Questions about this item

Will the 15 A total output limit kick in before the per-channel 6 A limit when I run all six channels at full brightness?

The controller caps each channel at 6 A and the combined draw at 15 A, so driving all six channels hard will hit the 15 A total limit first.

How much heat should I expect from the unit when it runs continuously at the 360 W maximum on a 24 V supply?

The controller is rated for an operating range of -25 °C to 45 °C; sustained 360 W loads will generate noticeable warmth, so ensure ventilation around the 74.5 × 35.6 × 16.5 mm enclosure.

Which power supply and LED strip must I already have to use this controller?

You need a DC 5 V, 12 V or 24 V supply matching your strip voltage (5.5 × 2.1 mm jack) and a 6-wire RGBCCT strip (V+, R, G, B, CW, WW) without an IC chip.
