Small white rectangular controller with screw terminals and DC power jack

KEHIPI

KEHIPI C03Z Zigbee 3.0 RGB LED Controller 6A/Ch 15A Max DC5-24V

SKU CH-X94G-FFAAG MPN C03Z

Controls 4-pin RGB LED strips at up to 6A per channel with 15A total across DC 5–24V, managed via Zigbee 3.0 and the Smart Life or Tuya Smart app

  • ColorWhite
  • SpecificationsBTF-LIGHTING
  • Dimensions3.0 in x 1.4 in x 0.7 in
  • Controls RGB strips via Zigbee 3.0 with Alexa and Google Home voice support
  • Delivers 6 A per channel up to 15 A total for bright colour mixing
  • Runs on DC 5 V to 24 V input matching common LED power supplies
  • Extends control range through auto-transmitting mesh up to 30 m between units
  • Synchronises multiple controllers automatically for consistent dynamic lighting effects

Zigbee 3.0 RGB LED Controller

The KEHIPI C03Z is a Zigbee 3.0 controller for 4-pin PWM RGB LED strips such as FCOB, COB, 5050, 3528 and similar types. It connects to a compatible Zigbee gateway and works with Alexa, Google Home and the Smart Life or Tuya Smart apps. Buyers who need an RF remote or SmartThings compatibility should choose a different model.

15 A total output across three channels

Each channel delivers up to 6 A with a combined maximum of 15 A. Power limits are 75 W at 5 V, 180 W at 12 V and 360 W at 24 V. The supply voltage must match the LED strip voltage. Strips that require an IC chip or more than three colour channels cannot be driven by this unit.

Screw terminals and app pairing

The controller measures 74.5 x 35.6 x 16.5 mm and uses a 5.5 × 2.1 mm DC input. Wiring is via screw terminals for V+, R, G and B leads. Pairing is done through the app with a Zigbee gateway; the device cannot be controlled directly by an RF remote. Multiple units auto-synchronise within 30 m when on the same dynamic mode.

Highlights

  • Controls RGB strips via Zigbee 3.0 with Alexa and Google Home voice support
  • Delivers 6 A per channel up to 15 A total for bright colour mixing
  • Runs on DC 5 V to 24 V input matching common LED power supplies
  • Extends control range through auto-transmitting mesh up to 30 m between units
  • Synchronises multiple controllers automatically for consistent dynamic lighting effects

Specifications

BrandBTF-LIGHTING
ModelC03Z
ColorWhite
Part NumberC03Z
SpecificationsBTF-LIGHTING
Dimensions3.0 in x 1.4 in x 0.7 in

Questions about this item

What does the 15 A total current limit mean for the LED strips I can run from this controller?

The controller supplies up to 6 A on each of its three colour channels but never more than 15 A combined, so at 12 V you can drive about 180 W of RGB strip and at 24 V about 360 W as long as the sum of the three channels stays under 15 A.

How does the Zigbee 3.0 connection affect the way I add this controller to my smart-home system?

It pairs directly with a Zigbee 3.0 coordinator such as an Echo Plus, Echo 4th Gen or a Tuya gateway, then appears in the Smart Life or Tuya Smart app for Alexa and Google Home voice control; it cannot join a SmartThings hub.

What physical space and wiring do I need to install the C03Z?

The unit measures 74.5 mm by 35.6 mm by 16.5 mm, accepts a 5.5 mm by 2.1 mm DC barrel jack for 5–24 V input, and provides a four-wire V+ R G B output for common-anode RGB strips.
