JUSHIDE
JUSHIDE JS-6615 Digital Servo 17kg IP66 Metal Gear Dual Ball Bearing
A waterproof IP66 digital servo delivering 17 kg-cm torque at 6.8 V with metal gears and dual ball bearings for 1/10 RC cars, robots and drones
- TypeSERVO
- Size/Dimensions6 x 6 x 3.3 cm (2.36 x 2.36 x 1.30 in)
- Length6 cm(2.36 in)
- Width6 cm (2.36 in)
- Height3.3 cm(1.30 in)
- Weight60g
- High torque of 17 kg-cm powers demanding RC cars and robots
- IP66 waterproof rating withstands harsh outdoor and off-road conditions
- Digital control system delivers fast response for precise movement
- Metal gears with dual ball bearings ensure durable and smooth operation
- Standard 6 cm size fits 1/10 scale cars, drones and airplanes
JUSHIDE JS-6615 Digital Servo 17kg IP66
The JUSHIDE JS-6615 is a standard-size digital servo built for 1/10 scale RC cars, robots, drones and airplanes. It delivers 17 kg-cm of torque at 6.8 V and uses a brushed motor with metal gears and dual ball bearings. The IP66 rating protects the unit against dust and powerful water jets. Programmable functions include direction, dead-band width and end-point adjustment.
Voltage and Current Limits
The servo operates from 4.8 V to 6.8 V, drawing up to 2500 mA continuously and 4500 mA in bursts. A supply that cannot sustain the burst current will cause voltage sag and reduced torque. The IP66 seal resists water jets but is not rated for continuous submersion. The brushed motor and gear train are designed for the stated torque; exceeding the load will accelerate wear.
Pre-Installation Checklist
Verify that your receiver and battery can provide 6.8 V and at least 4500 mA peak current. Confirm the 6 cm by 6 cm by 3.3 cm case fits the mounting area and that the output spline matches your servo horn. Ensure the control electronics support digital servo signal timing. The unit is not a startup kit, so no extra accessories are included.
Highlights
- High torque of 17 kg-cm powers demanding RC cars and robots
- IP66 waterproof rating withstands harsh outdoor and off-road conditions
- Digital control system delivers fast response for precise movement
- Metal gears with dual ball bearings ensure durable and smooth operation
- Standard 6 cm size fits 1/10 scale cars, drones and airplanes
Specifications
| Brand | JUSHIDE |
|---|---|
| Model Number | JS-6615 |
| Type | SERVO |
| Size/Dimensions | 6 x 6 x 3.3 cm (2.36 x 2.36 x 1.30 in) |
| Length | 6 cm(2.36 in) |
| Width | 6 cm (2.36 in) |
| Height | 3.3 cm(1.30 in) |
| Weight | 60g |
| Max Continuous Current | 2500mA |
| Max Burst Current | 4500mA |
| Voltage Range | 4.8V - 6.8V |
| Transistor Type | Brushed |
| Programmable Functions | Direction, Dead Band Width, End Point Adjustment |
| Compatibility | 1/10 RC Car, Robot, Drone, Airplane |
| Features | Waterproof IP66, Metal Gear, Digital Control, Dual Ball Bearing |
| Torque | 17 kg-cm @ 6.8V |
| Kit Type | Startup Kit - No |
Questions about this item
Is the JS-6615 sold in different torque versions or only as the 17 kg-cm model?
The JS-6615 is offered as a single standard-size servo rated at 17 kg-cm torque at 6.8 V, with no alternative torque versions listed.
What does the 17 kg-cm torque rating mean when the servo is installed in an RC car?
At 6.8 V the servo can hold 17 kg-cm, giving strong steering or throttle force for a 1/10 scale car, robot or drone under heavy load.
What control interface does the JS-6615 use and what voltage range does it support?
It uses a standard PWM signal lead and operates from 4.8 V to 6.8 V, with torque and speed scaling across that range.
