White rectangular timer module with LCD screen and buttons, DIN-rail mount, 72 by 45 by 110 mm

JinTaoRui

JinTaoRui TM618E AC 220V Digital Weekly Programmable Timer Switch

SKU CH-2E1G-YHMJ7

Digital weekly timer with 16 daily on/off programs and 15 weekly combinations for 220 V AC loads up to 16 A

  • Switch on/off any electrical equipment at preset times
  • 16 on/off programs daily with 15 weekly combinations
  • 24/7 programming with auto time correction ±30 sec weekly
  • Built-in rechargeable battery backs up programs for 60 days
  • 16 A rated current handles heavy loads directly

JinTaoRui TM618E weekly timer

The TM618E is a 220 V AC digital timer switch designed to automate electrical equipment such as streetlights, signage, appliances or broadcast gear. It provides direct voltage output matching the supply, allowing straightforward wiring without specialist help. The unit suits installers who need reliable weekly scheduling in a compact DIN-style module.

16 A load handling and 16 daily programs

The relay supports a 16 A resistive load, giving ample capacity for lighting circuits, pumps or small motors. Sixteen on/off programs per day can be combined into fifteen weekly patterns, while a minimum interval of one minute allows fine-grained control. A built-in 1.2 V 240 mA rechargeable battery preserves all settings for up to sixty days during power loss.

Low consumption and wide temperature range

Maximum power draw is 4.5 VA, so the timer adds negligible overhead to the installation. The CMOS chip delivers an average timing error of one second per day at 25 °C and operates reliably from -20 °C to +50 °C. The LCD display and LED indicators remain readable in normal indoor or cabinet environments.

Highlights

  • Switch on/off any electrical equipment at preset times
  • 16 on/off programs daily with 15 weekly combinations
  • 24/7 programming with auto time correction ±30 sec weekly
  • Built-in rechargeable battery backs up programs for 60 days
  • 16 A rated current handles heavy loads directly

Specifications

No published specifications for this item yet.

Questions about this item

Does the TM618E generate noticeable heat or noise when running continuously on a 220 V circuit?

The timer draws a maximum of 4.5 VA and uses a CMOS chip, so heat and audible noise remain negligible during all-day operation.

What wiring or accessories must I already have to install this timer switch?

You need a standard 220 V AC supply and the load you want to control; the unit provides direct voltage output so no extra contactor or relay is required.

Will the TM618E work reliably alongside older electromechanical timers on the same circuit?

Yes, its strong anti-jamming design and 1-second daily accuracy let it share a circuit with legacy timers without interference.
