Compact high-pressure arc lamp, matte metal body, ceramic base, 46 by 45 mm

Jaspertronics

Jaspertronics U-Stage 2R High-Pressure Stage Lamp Robe MiniPointe

SKU CH-SC9D-CS5C1

High-pressure short-arc stage lamp delivers 5150 lm at 8000K with 6000 h rated life for the Robe MiniPointe

  • TypeProject Lamp
  • ColorAssorted
  • Delivers 5150 lumens for bright stage output
  • 8000K color temperature produces crisp white light
  • 132W at 69V for efficient high-pressure operation
  • Universal burn position allows flexible fixture mounting
  • Rated 6000 hours average life reduces replacement frequency

Jaspertronics U-Stage 2R Stage Lamp

The Jaspertronics U-Stage 2R is a high-pressure short-arc discharge lamp rated at 132 W and 69 V. It delivers 5150 lm at a colour temperature of 8000 K with an average rated life of 6000 h. The lamp measures 46 x 45 mm and has a working distance of 37.7 mm. It is designed for moving-head fixtures such as the Robe MiniPointe and compatible models listed by the supplier.

Check fixture code and electrical specs

Verify that your moving-head fixture accepts lamp code 5002463 (2R) and can supply 69 V at 132 W. Confirm the burn position is universal and that the arc gap of .8 mm matches the original specification. Ensure the lamp dimensions of 46 x 45 mm fit the lamp housing and that the working distance of 37.7 mm aligns with the optical system.

Replaces 2R discharge lamps in listed fixtures

This lamp directly replaces Ushio NSL-132 2R and equivalent 2R lamps in fixtures including Elation Sniper 2R, Chauvet Rogue R1 Beam, ADJ Vizi Beam RXONE, Robe MiniPointe and others listed. The upgrade is worth it when the existing lamp has reached its 6000 h rated life or when output has dropped below the 5150 lm specification. It is not for fixtures requiring different wattage, voltage, base type or lamp codes such as 140 W, 150 W or 200 W models.

Highlights

  • Delivers 5150 lumens for bright stage output
  • 8000K color temperature produces crisp white light
  • 132W at 69V for efficient high-pressure operation
  • Universal burn position allows flexible fixture mounting
  • Rated 6000 hours average life reduces replacement frequency

Specifications

BrandJaspertronics
ModelRobe MiniPointe
Part NumberRobe MiniPointe
TypeProject Lamp
ColorAssorted

Questions about this item

What comes in the box with the Jaspertronics U-Stage 2R lamp and what must be purchased separately?

The box contains the 132 W high-pressure short-arc lamp with a 0.8 mm gap and 37.7 mm working distance. The Robe MiniPointe moving-head fixture or any compatible unit from the supported list must be bought separately.

Which version of the U-Stage 2R lamp should I choose for my fixture?

Choose the single 2R version identified by product code 5002463; it delivers 5150 lm at 8000 K, runs at 69 V and 132 W, and fits every moving head listed in the compatibility roster.

What does the 5150 lumen rating mean when the lamp is installed in a moving head?

At 8000 K colour temperature and a universal burn position, the 5150 lm output provides the intense beam punch required for stage, concert and nightclub moving-head fixtures such as the Robe MiniPointe over the rated 6000-hour life.
