Compact high-pressure arc lamp, rectangular metal housing with ceramic base, matte silver finish

Jaspertronics

Jaspertronics U-Stage 2R High-Pressure Stage Lamp for ADJ Vizi Beam RXONE

SKU CH-82Z9-P00ZN

High-pressure short-arc stage lamp delivering 5150 lm at 8000K with 6000-hour rated life for ADJ Vizi Beam RXONE fixtures

  • TypeProject Lamp
  • ColorAssorted
  • Delivers 5150 lumens for bright stage projection
  • 8000 K colour temperature creates crisp white light
  • 132 W at 69 V matches fixture power requirements
  • Universal burn position allows any mounting angle
  • 6000-hour rated life reduces replacement frequency

High-Pressure 2R Stage Lamp

The Jaspertronics U-Stage 2R is a high-pressure short arc discharge lamp built as a direct replacement for the ADJ Vizi Beam RXONE moving head fixture. It delivers 5150 lm at an 8000K colour temperature from a 132 W arc operating at 69 V. The universal burn position allows installation in any orientation required by the fixture design.

Straightforward Lamp Swap

Replacement consists of opening the fixture housing, unplugging the old lamp, and seating the new unit so its 0.8 mm arc gap aligns with the optical path. The 37.7 mm working distance and 46 x 45 mm envelope match the original specification, so no mechanical adjustment is needed. The most common error is touching the quartz envelope with bare fingers, which creates hot spots and shortens the 6000 h rated life.

Verify Fixture Compatibility

Before ordering, confirm that your moving head is listed among the supported models such as the ADJ Vizi Beam RXONE, Elation Rayzor Beam 2R, or Chauvet Rogue R1 Beam. Cross-reference the product code 5002463 (2R) with the fixture manual to ensure the correct lamp type is specified. Using this lamp in an unlisted fixture risks incorrect arc positioning and premature failure.

Highlights

  • Delivers 5150 lumens for bright stage projection
  • 8000 K colour temperature creates crisp white light
  • 132 W at 69 V matches fixture power requirements
  • Universal burn position allows any mounting angle
  • 6000-hour rated life reduces replacement frequency

Specifications

BrandJaspertronics
ModelADJ Vizi Beam RXONE
Part NumberADJ Vizi Beam RXONE
TypeProject Lamp
ColorAssorted

Questions about this item

How do I confirm the U-Stage 2R lamp is performing correctly after installation?

The fixture should produce a bright white beam at 8000K with 5150 lumen output. The 0.8 mm arc gap and universal burn position allow consistent ignition in any orientation.

What comes with the U-Stage 2R lamp and what must I source separately?

The package contains the 132W 69V high-pressure short arc lamp with 46 x 45 mm dimensions. The ADJ Vizi Beam RXONE moving head fixture and any mounting hardware are sold separately.

Which U-Stage 2R version should I choose for my ADJ Vizi Beam RXONE?

Select the 2R model with product code 5002463 rated at 132W, 69V, 5150 lumen and 6000 hour average life. This specification matches the ADJ Vizi Beam RXONE requirements exactly.
