Small rectangular bare discharge lamp with ceramic base and arc gap

Jaspertronics

Jaspertronics Sound Bridge Locus-LAMP 200W 5R DLP Replacement Lamp

SKU CH-2NEK-ZYBD1

A 200 W discharge lamp with a 1.1 mm arc gap, 7 200 lm output and 8 000 K colour temperature for the Sound Bridge Locus moving-head fixture

  • TypeProject Lamp
  • Weight0.2000
  • High intensity 7,200 lumen output for bright projection
  • 3,000-hour average life reduces replacement frequency
  • Compact 51 x 51 x 61 mm design fits fixture
  • Any burning position allows flexible installation
  • 8,000 K colour temperature delivers crisp white light

Jaspertronics Sound Bridge Locus Replacement Lamp

The Jaspertronics Sound Bridge Locus-LAMP is a 200W discharge lamp built for the Sound Bridge Locus moving-head fixture. It uses a YODN 5R short-arc design rated for 3,000 hours of average life and delivers 7,200 lumens at 8,000 K colour temperature. The lamp operates at 75 V with a 1.1 mm arc gap and fits the fixture's optical system for maximum output.

Stage lighting operators needing a direct 200W 5R

Venues running Sound Bridge Locus fixtures in worship, club, concert or theatre settings will find this lamp matches the original specification. Buyers whose fixtures require a different wattage, arc gap or base configuration should look elsewhere, as will anyone needing a lamp with a higher CRI than 70 or a longer rated life than 3,000 hours.

200W 5R discharge lamp with 1.1 mm arc gap

The critical specification is the 1.1 mm arc gap combined with 200 W power and 75 V operating voltage, which must match the fixture's ballast and optical alignment exactly. The lamp measures 51 x 51 x 61 mm with a 34.5 mm working distance and weighs 0.2000 kg, so physical compatibility depends on those dimensions alone.

Highlights

  • High intensity 7,200 lumen output for bright projection
  • 3,000-hour average life reduces replacement frequency
  • Compact 51 x 51 x 61 mm design fits fixture
  • Any burning position allows flexible installation
  • 8,000 K colour temperature delivers crisp white light

Specifications

BrandJaspertronics
ModelSound Bridge Locus-LAMP
Part NumberSound Bridge Locus-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

What are the physical dimensions of the 200W 5R discharge lamp?

The lamp measures 51 mm by 51 mm by 61 mm, with a working distance of 34.5 mm and an arc gap of 1.1 mm.

How is the bare bulb installed in the Sound Bridge Locus fixture, and what step is often missed?

Insert the lamp into the fixture socket, secure the retaining clips, then reset the fixture's lamp-hour counter so the new 3,000-hour life is tracked correctly.

When will the YODN 5R 200W lamp need replacement, and what indicates end of life?

Expect about 3,000 hours of use; replace when output drops noticeably or the arc becomes unstable, as the lamp reaches its rated average life.
