Compact bare arc lamp with rectangular ceramic base and quartz envelope

Jaspertronics

Jaspertronics PlatSpot5R-LAMP 200W DLP replacement lamp

SKU CH-19YH-GZZXG

200 W discharge arc lamp for the PlatSpot5R moving-head fixture, 7 200 lm at 8 000 K with 3 000 h average life

  • TypeProject Lamp
  • Weight0.2000
  • 200 W discharge lamp delivers 7 200 lm for bright moving-head output
  • 8 000 K colour temperature produces crisp white beam for stage and club use
  • 1 mm arc gap enables compact optical design with high intensity
  • Any burning position allows flexible fixture mounting without performance loss
  • 3 000 h average life reduces replacement frequency in houses of worship and concerts

Direct fit for PlatSpot5R fixtures

The Jaspertronics PlatSpot5R-LAMP is a 200 W discharge lamp built for the PlatSpot5R moving-head fixture. It delivers 7 200 lumens at an 8 000 K colour temperature with a CRI of 70. The compact arc design suits stage, club, theatre and house-of-worship lighting rigs.

Check fixture model and arc gap before ordering

Verify that your moving-head unit is the PlatSpot5R or another fixture that accepts the MSD200R5/MSD200S5 lamp code. The arc gap is 1.1 mm and the working distance is 34.5 mm, so the optical path must match those dimensions. Lamp voltage is 75 V and the lamp burns in any position.

Replaces a worn 200 W discharge lamp in the same

When output has dropped or the arc has become unstable after roughly 3 000 hours of use, this bare-bulb unit restores the original intensity and colour. The jump is worth it if the fixture optics and ballast are still serviceable and you need the full 7 200 lumen specification again.

Highlights

  • 200 W discharge lamp delivers 7 200 lm for bright moving-head output
  • 8 000 K colour temperature produces crisp white beam for stage and club use
  • 1 mm arc gap enables compact optical design with high intensity
  • Any burning position allows flexible fixture mounting without performance loss
  • 3 000 h average life reduces replacement frequency in houses of worship and concerts

Specifications

BrandJaspertronics
ModelPlatSpot5R-LAMP
Part NumberPlatSpot5R-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

What comes in the box with the PlatSpot5R-LAMP and is any extra hardware needed?

The box contains the bare 200 W discharge lamp only. No housing, cables or mounting hardware are included, so reuse the existing fixture housing when installing.

Which version of the 200 W lamp matches the PlatSpot5R fixture?

Select the YODN MSD200R5 or MSD200S5 coded lamp; both are listed as direct replacements for the PlatSpot5R moving head.

What does the 7 200 lumen rating mean when the lamp is running in the fixture?

At 7 200 lumens and 8 000 K colour temperature the lamp delivers high-intensity output suitable for stage, club and worship venues, with an average 3 000-hour life at 75 V arc voltage.
