Compact 200 W discharge lamp, 51 by 51 by 61 mm, bare bulb with 1.1 mm arc gap

Jaspertronics

Jaspertronics Elation Platinum Spot 5R-LAMP 200W DLP replacement lamp

SKU CH-NC00-TFP8F

A 200 W arc discharge lamp with 7,200 lm output and 8,000 K colour temperature for the Elation Platinum Spot 5R fixture

  • TypeProject Lamp
  • Weight0.2000
  • Designed for Elation Platinum Spot 5R fixtures
  • 200 W short-arc discharge lamp delivers 7,200 lm output
  • 8,000 K colour temperature with 70 CRI for vivid colour
  • Compact 51 x 51 x 61 mm size fits tight moving-head housings
  • Rated 3,000 hours average life for extended show cycles

Perfect Fixture Match

This 200W discharge lamp is built specifically for the Elation Platinum Spot 5R moving head fixture. It serves venues such as houses of worship, clubs, concerts, stages and theatres that need a direct replacement to keep shows running.

200 Watt Arc Output

The lamp runs at 200 watts with a 1.1 mm arc gap and 75 volt operating voltage. It delivers 7,200 lumens at an 8,000 K colour temperature and a CRI of 70, rated for a 3,000 hour average life in any burning position.

Bare Bulb Installation

The unit ships as a bare bulb without a module or housing, so technicians must install it into the existing fixture carrier. Its compact 51 x 51 x 61 mm dimensions and 34.5 mm working distance align with the original optical path for immediate use.

Highlights

  • Designed for Elation Platinum Spot 5R fixtures
  • 200 W short-arc discharge lamp delivers 7,200 lm output
  • 8,000 K colour temperature with 70 CRI for vivid colour
  • Compact 51 x 51 x 61 mm size fits tight moving-head housings
  • Rated 3,000 hours average life for extended show cycles

Specifications

BrandJaspertronics
ModelElation Platinum Spot 5R-LAMP
Part NumberElation Platinum Spot 5R-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

How bright is the 7,200 lumen output when the lamp is running in a Platinum Spot 5R fixture?

The 7,200 lumen rating is the rated output of the 200 W discharge lamp itself; actual brightness on stage depends on the fixture's optics and any gobos or filters in the light path.

What does the 1.1 mm arc gap mean for focus and optical alignment?

The 1.1 mm arc gap is the physical distance between the electrodes; the fixture's lens system is designed around this gap size to produce a sharp beam with even field distribution.

Will the 51 x 51 x 61 mm lamp body fit the Platinum Spot 5R housing without modification?

Yes, the lamp measures 51 x 51 x 61 mm and is built as a direct replacement for the Elation Platinum Spot 5R, so it seats in the existing lamp compartment without adapters.
