Small bare discharge lamp with metal electrodes and ceramic body, compact rectangular shape

Jaspertronics

Jaspertronics Elation Platinum Beam 5R-LAMP 200W DLP Replacement Lamp

SKU CH-FZQQ-CKFSW

A 200 W discharge lamp with 7 200 lm output and 8 000 K colour temperature for the Elation Platinum Beam 5R fixture

  • TypeProject Lamp
  • Weight0.2000
  • Delivers 7,200 lumens for bright projection
  • 8,000 K colour temperature ensures crisp whites
  • 200 W discharge arc lamp powers moving-head fixtures
  • 3,000-hour average life reduces replacement frequency
  • Compact 51 x 51 x 61 mm size fits Elation Platinum Beam 5R

Replacement lamp for Elation Platinum Beam 5R

This 200 W discharge lamp is built as a direct replacement for the Elation Platinum Beam 5R moving-head fixture. It suits venues such as houses of worship, clubs, concerts, stages and theatres that need a reliable short-arc source. The unit ships new and weighs 0.2000 kg.

Sustained output and arc stability

The lamp delivers 7,200 lumens at a correlated colour temperature of 8,000 K with a CRI of 70. Average rated life is 3,000 hours when operated at the specified 75 V and 200 W. The 1.1 mm arc gap and any burning position help maintain consistent intensity throughout extended shows.

Compact bare-bulb installation

The bare bulb measures 51 x 51 x 61 mm with a working distance of 34.5 mm, allowing it to fit the fixture’s optical chamber without adapters. Because it is a bare discharge lamp, handlers must avoid contaminating the quartz envelope and ensure the socket aligns precisely with the 1.1 mm arc gap.

Highlights

  • Delivers 7,200 lumens for bright projection
  • 8,000 K colour temperature ensures crisp whites
  • 200 W discharge arc lamp powers moving-head fixtures
  • 3,000-hour average life reduces replacement frequency
  • Compact 51 x 51 x 61 mm size fits Elation Platinum Beam 5R

Specifications

BrandJaspertronics
ModelElation Platinum Beam 5R-LAMP
Part NumberElation Platinum Beam 5R-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

How much heat and power does the 200 W discharge arc draw when the fixture runs all day?

The lamp runs at 200 W and 75 V with a 1.1 mm arc gap, so the fixture’s cooling must handle a continuous 200 W thermal load.

What fixture and electrical connections must I already own for this bare bulb to work?

It is built for the Elation Platinum Beam 5R moving-head fixture; the lamp seats in that fixture’s dedicated 5R socket and runs at 75 V / 200 W.

Will the 8 000 K colour temperature match the older lamps I keep as spares?

This replacement is rated at 8 000 K and 7 200 lm with a CRI of 70, so it will match other 5R lamps that share those specifications.
