A compact 200W discharge arc lamp with a bare quartz envelope measuring 51 by 51 by 61 millimetres

Jaspertronics

Jaspertronics Elation Platinum Beam 5R Extreme-LAMP 200W DLP Replacement Lamp

SKU CH-TWCA-JTN78

A 200 W discharge lamp with 1.1 mm arc gap delivers 7,200 lm at 8,000 K for the Elation Platinum Beam 5R Extreme fixture

  • TypeProject Lamp
  • Weight0.2000
  • 200 W discharge lamp powers intense beam output
  • 7 200 lumen rating delivers high brightness for stage use
  • 8 000 K colour temperature produces crisp white light
  • 3 000 hour average life supports extended run times
  • Compact 51 x 51 x 61 mm arc design fits Elation Platinum Beam 5R Extreme fixture

Purpose-built replacement

The Jaspertronics Elation Platinum Beam 5R Extreme-LAMP is a 200 W discharge lamp engineered specifically for the Elation Platinum Beam 5R Extreme moving-head fixture. It serves venues such as houses of worship, clubs, concerts, stage and theatre where a direct, high-intensity source is required.

Build and mounting

The compact bare-bulb measures 51 x 51 x 61 mm with a working distance of 34.5 mm and an arc gap of 1.1 mm, allowing it to seat precisely in the fixture’s optical path. Any burning position is supported, and the lamp weighs 0.2000 kg for straightforward handling during change-outs.

Output and lifespan

Rated at 7,200 lumens with an 8,000 K colour temperature and a CRI of 70, the lamp delivers the intense white beam the fixture is designed for. Average life is 3,000 hours at 75 V operating voltage, and the unit ships new with a three-month warranty.

Highlights

  • 200 W discharge lamp powers intense beam output
  • 7 200 lumen rating delivers high brightness for stage use
  • 8 000 K colour temperature produces crisp white light
  • 3 000 hour average life supports extended run times
  • Compact 51 x 51 x 61 mm arc design fits Elation Platinum Beam 5R Extreme fixture

Specifications

BrandJaspertronics
ModelElation Platinum Beam 5R Extreme-LAMP
Part NumberElation Platinum Beam 5R Extreme-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

What arc gap does the 200 W discharge lamp use?

The lamp has a 1.1 mm arc gap, which sets the voltage and intensity characteristics for the Elation Platinum Beam 5R Extreme fixture.

What are the physical dimensions of the bare bulb?

The bare bulb measures 51 x 51 x 61 mm with a working distance of 34.5 mm, so the fixture's lamp compartment must accommodate that envelope.

How is the lamp installed and what step is often missed?

Insert the bare bulb into the fixture's lamp holder, align the electrodes, then reset the fixture's lamp-hour counter; skipping the counter reset is the common error.
