Compact high-pressure stage lamp with cylindrical metal body and ceramic arc tube, 46 by 45 mm, silver-grey finish

Jaspertronics

Jaspertronics EK Lighting M130 U-Stage 2R High-Pressure Stage Lamp

SKU CH-CPKN-M9J2P

High-pressure short-arc stage lamp delivering 5150 lumens at 8000K colour temperature with a 6000-hour rated life for moving-head fixtures

  • TypeProject Lamp
  • ColorAssorted
  • High lumen output of 5150 lm for bright stage illumination
  • High colour temperature 8000K delivers crisp white light
  • Long average rated life of 6000 hours reduces replacement frequency
  • Universal burn position allows flexible fixture mounting
  • Compatible with multiple moving-head fixtures including Elation Sniper 2R and Chauvet Rogue R1 Beam

Replacement Lamp for EK Lighting M130 Fixtures

This 132W high-pressure short arc lamp is a direct replacement for the EK Lighting M130 moving head. It delivers 5150 lm at a cool 8000K colour temperature from a compact 46 x 45 mm envelope. The universal burn position allows installation in any orientation required by the fixture design.

Suits Touring Rental Stock Not Home Decor

The lamp fits professional moving heads such as the Elation Sniper 2R, Martin Rush MH4 and Chauvet Rogue R1 Beam, making it ideal for rental houses and touring crews. Buyers needing a standard household screw-base bulb or a low-heat LED alternative for architectural lighting should look elsewhere.

Quick Swap With Correct Arc Alignment

Installation consists of opening the fixture head, seating the lamp so the 0.8 mm arc gap sits at the 37.7 mm working distance, and securing the retainer. Misalignment of the arc is the most common cause of hot spots or premature failure, so verify focus before striking.

Highlights

  • High lumen output of 5150 lm for bright stage illumination
  • High colour temperature 8000K delivers crisp white light
  • Long average rated life of 6000 hours reduces replacement frequency
  • Universal burn position allows flexible fixture mounting
  • Compatible with multiple moving-head fixtures including Elation Sniper 2R and Chauvet Rogue R1 Beam

Specifications

BrandJaspertronics
ModelEK Lighting M130
Part NumberEK Lighting M130
TypeProject Lamp
ColorAssorted

Questions about this item

Does the EK Lighting M130 moving head fixture need to be on hand for this 2R lamp to operate?

Yes, the Jaspertronics U-Stage 2R lamp is built specifically for the EK Lighting M130 moving head and compatible models such as the Chauvet Rogue R1 Beam or ADJ Vizi Beam RXONE.

Will the 69 V, 132 W arc specification match the ballast in my older 2R moving heads?

The lamp runs at 69 volts and 132 watts with a 0.8 mm arc gap, matching the electrical requirements of listed 2R fixtures including the Martin Rush MH4 and Mega Lite Axis Beam 2R.

How can I confirm the lamp is performing correctly once installed?

Expect a 8000 K colour temperature and 5150 lumen output at the 37.7 mm working distance; the rated life is 6000 hours under universal burn position.
