Bare 380W 18R discharge lamp module, compact rectangular housing with arc tube visible

Jaspertronics

Jaspertronics AOYALONG B380SW-LAMP 380W 18R dlp replacement lamp

SKU CH-H3E3-M4DN8

A 380 W 18R discharge lamp rated at 20 000 lm and 7 500 K for AOYALONG B380SW and compatible moving-head fixtures

  • TypeProject Lamp
  • Weight0.2000
  • 380 W arc discharge lamp delivers 20 000 lumens for intense beam output
  • Compact 58 x 58 x 66 mm body fits tight moving-head housings
  • 2 mm arc gap and 7 500 K colour temperature produce sharp white light
  • Compatible with AOYALONG B380SW and 20-plus other fixture models
  • 1 500-hour average life reduces relamp frequency in clubs and theatres

Fixture Compatibility

This replacement lamp fits the AOYALONG B380SW fixture and a wide range of moving-head units including Acme XP-380 BEAM, Martin Professional ERA 500 Hybrid IP, and YAFENG XT-9000. It is intended for venues such as houses of worship, clubs, concerts, and theatres that need a direct swap for a 380 W discharge source.

Build and Mounting

The bare bulb measures 58 x 58 x 66 mm with a working distance of 31.42 mm and an arc gap of 1.2 mm, allowing it to seat in the listed fixtures without modification. Its any burning position rating gives installers flexibility when mounting the lamp in different fixture orientations.

Upgrade Context

The lamp delivers 20,000 lumens at 7,500 K with a CRI of 80 and an average life of 1,500 hours, replacing worn or dimmed 380 W beam lamps in the same fixtures. The jump is worth it when output has dropped below usable levels or when colour consistency across a rig has drifted. It is not for users who need a higher-wattage source or a different arc technology.

Highlights

  • 380 W arc discharge lamp delivers 20 000 lumens for intense beam output
  • Compact 58 x 58 x 66 mm body fits tight moving-head housings
  • 2 mm arc gap and 7 500 K colour temperature produce sharp white light
  • Compatible with AOYALONG B380SW and 20-plus other fixture models
  • 1 500-hour average life reduces relamp frequency in clubs and theatres

Specifications

BrandJaspertronics
ModelAOYALONG B380SW-LAMP
Part NumberAOYALONG B380SW-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

What wattage and arc gap does the 380W 18R lamp specify?

The lamp is rated at 380 W with a 1.2 mm arc gap, delivering 20,000 lumens at 7,500 K colour temperature and a CRI of 80.

What are the physical dimensions and working distance for mounting in the AOYALONG B380SW fixture?

The bare bulb measures 58 × 58 × 66 mm and has a working distance of 31.42 mm, matching the fixture's lamp housing requirements.

How is the lamp installed and which orientation step is often missed?

Insert the bare bulb into the fixture's lamp holder, secure the retaining clips, and reset the lamp-hour counter; the burning position is rated for any orientation, so no specific alignment is required.
