Jaspertronics American DJ Vizi Beam 5RX-LAMP 200W DLP Replacement Lamp

Direct replacement for ADJ Vizi Beam 5RX

This Jaspertronics 200 W discharge lamp is built as a direct replacement for the American DJ Vizi Beam 5RX moving-head fixture. It uses a YODN 5R short-arc design rated at 7 200 lm and 8 000 K colour temperature. The lamp weighs 0.2 kg and fits the fixture's existing mounting without modification.

Practical limits of the 5R discharge standard

The arc gap is fixed at 1.1 mm and the lamp runs at 75 V, so it must be powered by a ballast that matches those electrical parameters. Average life is rated at 3 000 hours, after which output and colour stability will decline. Burning position is unrestricted, but the compact 51 × 51 × 61 mm envelope and 34.5 mm working distance leave no room for alternative reflectors or lenses.

Installation notes and common pitfalls

The bare bulb slides into the fixture's lamp holder and seats against the 34.5 mm working-distance stop; no tools are required beyond those supplied with the fixture. The most frequent error is touching the quartz envelope with bare fingers, which creates hot spots and shortens life — always handle with clean gloves or the supplied cloth. Verify the ballast is set for 200 W 5R operation before striking the arc.
