A bare discharge arc lamp, compact rectangular form, clear glass envelope, metal base visible

Jaspertronics

Jaspertronics ACT CPL10103-LAMP 200W 5R dlp replacement lamp

SKU CH-85Z2-9BQ7H

200 W short-arc discharge lamp for ACT CPL10103 moving-head fixtures, 7 200 lm at 8 000 K with 3 000-hour rated life

  • TypeProject Lamp
  • Weight0.2000
  • 200 W discharge arc powers bright moving-head output
  • 7,200 lumen output delivers intense stage illumination
  • 8,000 K colour temperature creates crisp white light
  • 3,000 hour rated life supports extended show runs
  • Compact 51 x 51 x 61 mm size fits ACT CPL10103 fixture

Lamp purpose

The Jaspertronics ACT CPL10103-LAMP is a 200W discharge lamp built for the ACT CPL10103 moving-head fixture. It serves venues such as houses of worship, clubs, concerts, stage and theatre that need a compact high-intensity source with a long reliable lifetime.

Build fit

The bare bulb measures 51 x 51 x 61 mm with a 34.5 mm working distance and a 1.1 mm arc gap, so it slots into the fixture’s optical path without adapters. Its any-position burning capability frees the designer from orientation constraints during rigging.

Sustained output

Rated at 7 200 lumens and 8 000 K with a CRI of 70, the lamp runs at 75 V and delivers stable output across its 3 000-hour average life. The 0.2 kg weight keeps structural load low during extended shows.

Highlights

  • 200 W discharge arc powers bright moving-head output
  • 7,200 lumen output delivers intense stage illumination
  • 8,000 K colour temperature creates crisp white light
  • 3,000 hour rated life supports extended show runs
  • Compact 51 x 51 x 61 mm size fits ACT CPL10103 fixture

Specifications

BrandJaspertronics
ModelACT CPL10103-LAMP
Part NumberACT CPL10103-LAMP
TypeProject Lamp
Weight0.2000

Questions about this item

How long before the 200 W lamp reaches its 3 000 hour average life under continuous operation?

The lamp is rated for an average life of 3 000 hours at 200 W output.

What heat or power draw should I expect from the 75 V arc during all-day use?

The lamp runs at 75 V and 200 W, producing high intensity light with a 1.1 mm arc gap.

Which fixture and electrical connection does the ACT CPL10103-LAMP require to operate?

It fits the ACT CPL10103 fixture and uses a 75 V arc connection with a 34.5 mm working distance.
