Jansicotek
Jansicotek YCY-2353 USB 3.0 1080p 60Hz video capturing device
Captures HDMI video at up to 1080p 60Hz and passes through 4K 30Hz, with USB 3.0 output, 48 KHz audio, and a 3.5 mm mic input for commentary
- InterfaceUSB 3.0
- FormatOutput Video Formats: vif,mp4,mov,mkv,ts,m3u8 and more
- Resolution Support1080P
- Camera ResolutionUp to 1080p Video
- ColorBlack
- VideoThe recorded video signal can reach 1080p / 60Hz, HDMI input
- Capture 1080p at 60Hz for smooth recordings
- Pass-through 4K input at 30Hz to a display
- USB 3.0 delivers 300-350MB/s throughput for low latency
- 48KHz PCM audio plus 3.5mm mic input for commentary
- Works on Windows, macOS 10.9+, Linux and Android without extra drivers
Jansicotek YCY-2353 USB 3.0 Capture Device
The Jansicotek YCY-2353 is a USB 3.0 video capturing device built for streamers and content creators who need to record or broadcast gameplay from consoles or cameras. It accepts an HDMI signal up to 4K at 30 Hz and passes through a loop-out for a local display. The unit draws power directly from the USB port, requiring no external adapter.
1080p 60 Hz Recording Specification
The single specification that decides suitability is the maximum recorded output of 1080p at 60 Hz, even though the HDMI input can accept 4K at 30 Hz. If your workflow demands capturing 4K resolution, this device will downscale to 1080p. It supports MJPEG and YUY2 formats and 48 KHz PCM audio sampling over UAC and UVC protocols.
Sustained USB 3.0 Throughput Behaviour
Under continuous capture the device delivers 300 to 350 MB/s over USB 3.0, maintaining stable frame rates without dropped frames during long sessions. On a USB 2.0 connection bandwidth falls to roughly 40 MB/s, which limits practical use to lower resolutions. The aluminium body aids passive heat dissipation during extended operation.
Highlights
- Capture 1080p at 60Hz for smooth recordings
- Pass-through 4K input at 30Hz to a display
- USB 3.0 delivers 300-350MB/s throughput for low latency
- 48KHz PCM audio plus 3.5mm mic input for commentary
- Works on Windows, macOS 10.9+, Linux and Android without extra drivers
Specifications
| Brand | Jansicotek |
|---|---|
| Series | YCY-2353 |
| Model | YCY-2353 |
| Interface | USB 3.0 |
| Format | Output Video Formats: vif,mp4,mov,mkv,ts,m3u8 and more |
| Resolution Support | 1080P |
| Camera Resolution | Up to 1080p Video |
| Color | Black |
| Video | The recorded video signal can reach 1080p / 60Hz, HDMI input supports 4K / 30Hz; |
| Audio | support 48 KHz PCM audio sampling rate |
| HDMI | 1 Input/1 Output |
| USB Port | 1 |
| S-Video | 1 Input/1 Output |
| LED Indicator | Yes |
| Display | HDMI Output : apply for all TV, Monitor, Projector, LCD and other displays which equipped with HDMI output port;It can automatically detect the input video formats and it will adjust to the set output size and frame rate automatically. |
| Compatibility | The HDMI video capture card is a good helper for high-definition capture, live broadcast,video recording, conference room, teaching recording and gameplay. Can be connected to source HDMI interface devices (such as: PS3, PS4, NS switch, XBOX, computer, laptop, DVD, HD player, etc.) Real-time game capture card for switch streaming on Twitch/Youtube/OBS/XSplit/Potplayer/Tiktok. |
| System Requirements | Windows / Android / MacOS/ Linux ect. |
| Power Consumption | <= 2.5W |
| Power Supply | NO need external power supply |
| Specification | 1. Input interface: 1 HDMI interface; 2. Output interface: USB3.0, 300 ~ 350MB / s throughput; 3. HDMI input: 4K / 30Hz, 1080P / 60, 59.94, 50, 30, 29.97, 25, 24, 23.98, 1080i 50/60, 720P 50 / 60,480P, 576P1280x1024, 1280x960, 1024x768, 800x600, 640x480 4. HDMI sound input: LPCM sound signal; 5. HDMI input format: compatible with HDMI1.4 standard, maximum bandwidth support 225MHz 4K / 30Hz, 12bit deep color; 6. Output format Resolutions: 640x480 / 720x480 / 720x576 / 800x600 / 1024x768 / 1280x720 / 1280x960 / 1280x1024 / 1366x768 / 1360x768 / 1440x900 / 1400x900 / 1680x1050 / 1920x10 |
| Feature | 1. It can capture single HD HDMI video signal; 2. The recorded video signal can reach 1080p / 60Hz, HDMI input supports 4K / 30Hz; 3. Support MJPEG and YUY2; 4.Support UAC & UVC agreement, support 48 KHz PCM audio sampling rate; 5. Some win7 need to install the driver; 6. Compatible with Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS operating systems; 7. USB3.0, 300 ~ 350MB / s bandwidth, compatible with USB 2.0 (40MB / s bandwidth); 8. Can automatically detect the input video format, and automatically adjust to the set output size and frame rate; 9. Can automatically detect the i |
| Dimensions | 4.88 x 4.65 x 2.52 inches |
| Weight | 0.035 ounces |
| Package Content | 1 x4K USB3.0 HDMI Audio Video Capture Card; 1 x HDMI Cable; 1xUSB 3.0 Cable; 1 x User Manual; |
| Option | Advanced |
Questions about this item
What does 1080p 60Hz mean for my stream or recording?
The device captures gameplay or camera feeds at full 1080p resolution and 60 frames per second, so fast motion stays smooth when you stream to Twitch, YouTube or record in OBS.
How does the USB 3.0 connection limit what I can capture?
USB 3.0 provides 300–350 MB/s bandwidth, enough for 1080p 60Hz capture; if you plug into a USB 2.0 port the link drops to 40 MB/s and cannot sustain that frame rate.
What ports and cables do I need to hook this up?
One HDMI input from your console or camera, one HDMI loop-out to a monitor, a USB 3.0 cable to the PC, and a 3.5 mm TRS microphone if you want live commentary.
