Jansicotek
Jansicotek YCY-2353 USB 3.0 1080p 60 Hz video capturing device
A USB 3.0 capture card recording 1080p at 60 Hz from HDMI sources while passing 4K 30 Hz through to a display
- InterfaceUSB 3.0
- FormatOutput Video Formats: vif,mp4,mov,mkv,ts,m3u8 and more
- Resolution Support1080P
- Camera ResolutionUp to 1080p Video
- ColorBlack
- VideoThe recorded video signal can reach 1080p / 60Hz, HDMI input
- Captures 1080p at 60 Hz for smooth gameplay recording
- HDMI pass-through supports 4K 30 Hz input while you record
- USB 3.0 delivers 300–350 MB/s bandwidth for low-latency streaming
- Works with Windows, macOS 10.9+, Linux and Android without extra drivers
- 5 mm TRS mic input lets you add live commentary
Capture resolution and frame rate
The Jansicotek YCY-2353 captures a single HDMI video signal at up to 1080p 60 Hz while accepting 4K 30 Hz input. It encodes using MJPEG or YUY2 and records 48 KHz PCM audio. The USB 3.0 interface provides 300–350 MB/s throughput and falls back to USB 2.0 at 40 MB/s. No external power supply is required.
Thermals noise and power draw
The device draws 2.5 W or less directly from the USB port, so it adds negligible heat to a workstation. There are no moving parts, making operation completely silent during live streaming, recording or conferencing. An LED indicator shows link status without contributing audible noise. Automatic format detection keeps the pipeline stable across Windows, macOS, Linux and Android.
Sustained-load behaviour
During long capture sessions the hardware maintains 1080p 60 Hz output without frame drops, relying on the host CPU for encoding rather than onboard processing. The 3.5 mm TRS microphone input allows live commentary but does not record party chat. HDMI pass-through lets a monitor or projector display the source signal simultaneously. Some Windows 7 installations require a driver install before use.
Highlights
- Captures 1080p at 60 Hz for smooth gameplay recording
- HDMI pass-through supports 4K 30 Hz input while you record
- USB 3.0 delivers 300–350 MB/s bandwidth for low-latency streaming
- Works with Windows, macOS 10.9+, Linux and Android without extra drivers
- 5 mm TRS mic input lets you add live commentary
Specifications
| Brand | Jansicotek |
|---|---|
| Series | YCY-2353 |
| Model | YCY-2353 |
| Interface | USB 3.0 |
| Format | Output Video Formats: vif,mp4,mov,mkv,ts,m3u8 and more |
| Resolution Support | 1080P |
| Camera Resolution | Up to 1080p Video |
| Color | Black |
| Video | The recorded video signal can reach 1080p / 60Hz, HDMI input supports 4K / 30Hz; |
| Audio | support 48 KHz PCM audio sampling rate |
| HDMI | 1 Input/1 Output |
| USB Port | 1 |
| S-Video | 1 Input/1 Output |
| LED Indicator | Yes |
| Display | HDMI Output : apply for all TV, Monitor, Projector, LCD and other displays which equipped with HDMI output port;It can automatically detect the input video formats and it will adjust to the set output size and frame rate automatically. |
| Compatibility | The HDMI video capture card is a good helper for high-definition capture, live broadcast,video recording, conference room, teaching recording and gameplay. Can be connected to source HDMI interface devices (such as: PS3, PS4, NS switch, XBOX, computer, laptop, DVD, HD player, etc.) Real-time game capture card for switch streaming on Twitch/Youtube/OBS/XSplit/Potplayer/Tiktok. |
| System Requirements | Windows / Android / MacOS/ Linux ect. |
| Power Consumption | <= 2.5W |
| Power Supply | NO need external power supply |
| Specification | 1. Input interface: 1 HDMI interface; 2. Output interface: USB3.0, 300 ~ 350MB / s throughput; 3. HDMI input: 4K / 30Hz, 1080P / 60, 59.94, 50, 30, 29.97, 25, 24, 23.98, 1080i 50/60, 720P 50 / 60,480P, 576P1280x1024, 1280x960, 1024x768, 800x600, 640x480 4. HDMI sound input: LPCM sound signal; 5. HDMI input format: compatible with HDMI1.4 standard, maximum bandwidth support 225MHz 4K / 30Hz, 12bit deep color; 6. Output format Resolutions: 640x480 / 720x480 / 720x576 / 800x600 / 1024x768 / 1280x720 / 1280x960 / 1280x1024 / 1366x768 / 1360x768 / 1440x900 / 1400x900 / 1680x1050 / 1920x10 |
| Feature | 1. It can capture single HD HDMI video signal; 2. The recorded video signal can reach 1080p / 60Hz, HDMI input supports 4K / 30Hz; 3. Support MJPEG and YUY2; 4.Support UAC & UVC agreement, support 48 KHz PCM audio sampling rate; 5. Some win7 need to install the driver; 6. Compatible with Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS operating systems; 7. USB3.0, 300 ~ 350MB / s bandwidth, compatible with USB 2.0 (40MB / s bandwidth); 8. Can automatically detect the input video format, and automatically adjust to the set output size and frame rate; 9. Can automatically detect the i |
| Dimensions | 4.88 x 4.65 x 2.52 inches |
| Weight | 0.035 ounces |
| Package Content | 1 x4K USB3.0 HDMI Audio Video Capture Card; 1 x HDMI Cable; 1xUSB 3.0 Cable; 1 x User Manual; |
| Option | Advanced |
Questions about this item
How do I connect the Jansicotek YCY-2353 to my PC and what is the common mistake?
Plug the HDMI source into the capture card's HDMI input, then connect the card to a USB 3.0 port on the PC; the frequent error is using a USB 2.0 port which limits bandwidth to 40 MB/s instead of 300–350 MB/s.
What upkeep does the YCY-2353 require over time?
No internal maintenance is needed; keep the HDMI and USB ports dust-free, ensure the 3.5 mm TRS microphone jack stays clean, and verify the LED indicator lights during operation.
What is the first limitation I hit during long capture sessions?
The device caps recorded video at 1080p 60 Hz while HDMI input accepts 4K 30 Hz, and sustained throughput is bounded by the USB 3.0 link at 300–350 MB/s.
