Small black rectangular capture dongle with HDMI and USB ports

Jansicotek

Jansicotek OZC1 USB 2.0 HDMI Video Capturing Device 1080p 4K Input

SKU CH-ACSJ-FBZTX

Captures 4K HDMI input and delivers 1080p output over USB 2.0 for streaming or recording

  • InterfaceUSB 2.0
  • FormatYUV / JPEG; Support audio format: L-PCM
  • Resolution Support1080P
  • Camera ResolutionUp to 1080p Video
  • ColorBlack
  • HDMI1 In
  • Capture 4K input at 60 Hz for high-resolution sources
  • Output 1080p at 60 Hz for smooth streaming and recording
  • Works with Windows, Mac and Linux without extra drivers
  • Compatible with OBS, VLC and Amcap for flexible workflows
  • Compact USB 2.0 design draws only 0.4 A and needs no external power

Capture resolution limits

The Jansicotek OZC1 accepts an HDMI signal up to 3840×2160 at 60 Hz but captures only up to 1920×1080 at 30 Hz over USB 2.0. It is aimed at streamers, educators or meeting hosts who need a simple way to bring a camera or console feed into OBS, VLC or Amcap on Windows, macOS or Linux.

Sustained capture behaviour

Because the USB 2.0 link caps throughput, the device cannot maintain 4K capture; it downscales to 1080p at 30 Hz during long sessions. The 8/10/12-bit deep-colour pipeline and L-PCM audio pass through without added latency, and the .4 A draw means no external power is required for continuous operation.

Installation and common issues

Plug the HDMI source into the single input, connect the supplied USB cable to a 2.0 port, and the UVC/UAC device appears in streaming software instantly. The 15-metre AWG26 cable limit applies at 1080p and below; longer runs or 4K sources may lose signal. No drivers are needed, but USB 3.0 ports on some laptops can cause detection problems.

Highlights

  • Capture 4K input at 60 Hz for high-resolution sources
  • Output 1080p at 60 Hz for smooth streaming and recording
  • Works with Windows, Mac and Linux without extra drivers
  • Compatible with OBS, VLC and Amcap for flexible workflows
  • Compact USB 2.0 design draws only 0.4 A and needs no external power

Specifications

BrandJansicotek
SeriesOZC1
ModelOZC1
InterfaceUSB 2.0
FormatYUV / JPEG; Support audio format: L-PCM
Resolution Support1080P
Camera ResolutionUp to 1080p Video
ColorBlack
HDMI1 In
USB Port1
SoftwareSupport most acquisition software, such as VLC / OBS / Amcap, etc
CompatibilityCompatible with Windows, Mac, and Linux. Easily connect your DSLR, camcorder, or action camera to your PC or Mac. Makes it easier for you to have real-time streaming for Twitch, Youtube, OBS, Potplayer and VLC
System RequirementsConnect your DSLR, camcorder or action camera to your Windows, MacOS and Linux.
SpecificationSupport Output Resolution: 1080P@60Hz Max
Support Input Resolution: 4K @60Hz Max
Support Color: 8/10/12bit deep color
Support Cable: AWG26 HDMI standard cable, input up to 15 meters (1080P and below resolution);
Video Output Format: YUV / JPEG; Support audio format: L-PCM
Max Working Current: 0.4A/5V DC
Operating Temperature Range: -10 to +55?
Dimension: 64x28x13 (mm); Weight: 21.4g
FeatureHDMI audio and video signals can be transmitted to the computer and smartphone for preview and storage, now you can enjoy stunning real-time video streaming.
It support HDMI input 3840x2160P and USB output (capture) 1920x1080P video and stereo sound.
Connect (SLR camera, camcorder or motion camera) to (Windows, MacOS, Android or Linux) to easily get real-time streaming media from software such as OBS Studio, Zoom, Potplayer, Twitch, Youtube, and VLC.
No driver or external power supply, suitable for high-definition acquisition, teaching recoding, Gaming, medical imaging, live streamin
Dimensions5.71 x 4.57 x 0.59 inches
Weight1.76 ounces
Package ContentAudio Video Capture Cards 1PCSUser Manual 1PCS
OptionHDMI and USB - 1080p

Questions about this item

Does the Jansicotek OZC1 get warm or draw much power when capturing all day?

It draws a maximum working current of .4 A at 5 V DC and needs no external power supply, so heat and power draw stay low during extended use.

What cables or host ports do I already need to use the OZC1?

You need an HDMI source, an AWG 26 HDMI cable up to 15 m long, and a free USB 2.0 port on a Windows, macOS or Linux computer.

Will the OZC1 downscale my 4K camera cleanly for a 1080p stream in OBS?

Yes — it accepts 3840×2160 at 60 Hz input and outputs 1920×1080 at up to 60 Hz in YUV or JPEG, compatible with OBS and other UVC software.
