Accsoon
Accsoon CineView SE Multi-Spectrum Wireless Video Transmitter 1200ft 1080p HDMI SDI
$181.99
0.00215979BTC
In stock
Jansicotek
Jansicotek 6x1 HDMI Multiviewer 4K@30Hz 8 Modes
Displays six HDMI sources on one screen with eight split modes, 4K@30Hz output and seamless switching via remote or front button
- TypeProfessional Video Devices
- Remote ControlRemote Included
- InterfaceHDMI
- Ports In1 HDMI
- Ports Out6 HDMI
- SpecificationsSupport HDMl resolution:24/ 50/ 60fs/ 4K30Hz/ 1080P/ 1080i/
- Seamless switching across six HDMI sources with zero wait time
- Eight split-screen layouts from full-screen to six-way view
- 4K at 30 Hz and 1080p at 60 Hz output resolution
- Infrared remote and front-panel buttons for flexible control
- Supports 24/30/36-bit colour and DTS-HD, Dolby TrueHD, AC3 audio
Purpose & Audience
The Jansicotek 6x1 HDMI Multiviewer combines six HDMI inputs into a single output for simultaneous multi-source monitoring. It suits security operators, broadcast technicians and live-production crews who need to view multiple cameras or playback devices on one display.
Decisive Specification
The unit accepts six HDMI sources and drives one HDMI output at up to 4K@30Hz or 1080P@60Hz with HDCP 1.4 compliance. Eight selectable layout modes — full, dual, triple, quad, penta and hexa screen — determine whether this multiviewer matches the required monitoring workflow.
Sustained-Load Behaviour
Seamless switching changes active sources instantly without signal drop or re-sync delay during continuous operation. The included 5V/2.1A power adapter maintains stable output through extended sessions, while IR remote and front-panel buttons allow layout changes without interrupting the video wall.
Highlights
- Seamless switching across six HDMI sources with zero wait time
- Eight split-screen layouts from full-screen to six-way view
- 4K at 30 Hz and 1080p at 60 Hz output resolution
- Infrared remote and front-panel buttons for flexible control
- Supports 24/30/36-bit colour and DTS-HD, Dolby TrueHD, AC3 audio
Specifications
| Brand | ESTONE |
|---|---|
| Model | OZJQF2 |
| Type | Professional Video Devices |
| Remote Control | Remote Included |
| Interface | HDMI |
| Ports In | 1 HDMI |
| Ports Out | 6 HDMI |
| Specifications | Support HDMl resolution:24/ 50/ 60fs/ 4K30Hz/ 1080P/ 1080i/ 720p/ 576p/ 576i/ 480p/ 480i. Support video color format:24bit/ 30bit/ 36bit. Support audio input format:DTS-HD/ Dolby-realHD/ Dolby-AC3/ DSD. Support audio output format: LPCM,PCM2. Max bandwidth:330Mhz. Max bandrate: 10.2Gbps. Input/Output TMDS signal:0.5~1.5V p-p(TTL). Input/Output DDc signal: 5Volts p-p(TTL). Input cable distance: =15mAWG24 HDM standard cable. Output cable distance: =24mAWG24 HDMl standard cable. Max working current: 12V/0.6A. |
| Package Contents | 6x1 HDMI video wall controller * 1; Remote Control (without battery) * 1; 5V/2.1A Power Adapter * 1; User Manual * 1 |
Questions about this item
What does 4K@30Hz mean when the multiviewer is connected to a display?
The device can output a 4K picture at 30 frames per second to the connected screen; in multi-view modes each of the six inputs is scaled to fit its window
What does the HDMI 1.4 interface cap in practice?
HDMI 1.4 limits the output to 4K at 30 Hz and 1080p at 60 Hz; higher refresh rates at 4K are not possible through this connection
What does the unit need to fit or mount in a rack or on a desk?
The package includes the 6x1 video wall controller, a remote control, a 5V 2.1A power adapter and a user manual; no rack ears or mounting brackets are mentioned
