A pair of small black metal boxes with HDMI and LC fiber ports, plus USB and power connectors

Jansicotek

Jansicotek 4K@60Hz HDMI Extender Kit LC Fiber 20km KVM Loop Out

SKU CH-MCXV-9PFSB

Transmits 4K@60Hz HDMI video, audio and USB KVM control up to 20 km over LC single-mode fiber with a local HDMI loop-out and zero latency

  • Device TypeTransceiver
  • Transfer Rate10Gbps
  • Power AdapterDC 12V/1A
  • FeatureLong range transmission:up to 20 km over a single-mode/Multi
  • Package ContentsHDMI extender Fiber transmitter ……………………1 pcs HDMI extender
  • 4K@60Hz uncompressed video over single-mode fibre up to 20 km
  • Remote USB keyboard and mouse control with zero-latency KVM function
  • Local HDMI loop-out on transmitter for dual-monitor setup
  • Bi-directional IR pass-through 20–60 kHz for source and display control
  • HDMI 2.0b and HDCP 2.2 compliant with automatic signal optimisation

Product Identity

The Jansicotek 4K@60Hz HDMI Extender Kit transmits uncompressed video, audio and USB KVM signals up to 20 km over a single LC single-mode or multi-mode fiber link. It targets installers and operators who need lossless 4K extension with local loop-out and remote keyboard-mouse control in broadcast, signage or industrial environments.

Thermals Noise Power

The transmitter and receiver each ship with a dedicated DC 12V/1A power adapter, so both endpoints draw power independently from a standard mains supply. No active cooling fans are mentioned in the specifications, indicating silent operation suitable for noise-sensitive control rooms or studio settings.

Upgrade Path

This kit replaces copper HDMI runs or lower-distance fiber extenders that cannot reach 20 km, lack KVM support or omit a local HDMI loop output. The jump is worth it when the installation requires true 4K@60Hz fidelity, bi-directional IR and USB-HID control across campus-scale distances without compression artefacts or added latency.

Highlights

  • 4K@60Hz uncompressed video over single-mode fibre up to 20 km
  • Remote USB keyboard and mouse control with zero-latency KVM function
  • Local HDMI loop-out on transmitter for dual-monitor setup
  • Bi-directional IR pass-through 20–60 kHz for source and display control
  • HDMI 2.0b and HDCP 2.2 compliant with automatic signal optimisation

Specifications

Device TypeTransceiver
Transfer Rate10Gbps
Power AdapterDC 12V/1A
FeatureLong range transmission:up to 20 km over a single-mode/Multi-mode LC fiber optic cable;
Video resolution: 480P,720P,720i,1080i,1920*1080P@60/120Hz,4K@30/60Hz;
Audio Format: DTS-HD/Dolby-true HD/LPCM7.1/DTS/DSD ;
Uncompressed,No loss,No delay;
Infrared control:Bi-directional 20~60 KHz IR romote control;
KVM Control:supports remote USB KVM control by keyboard & mouse;
HDMI Loop Out:The transmitter with one HDMI loop output;
Video standard:compliance with HDMI 2.0b and HDCP 2.2 standard;
Built-in automatic adjustment system: make the image smooth, clear and stable;
Built-in ESD protecti
Package ContentsHDMI extender Fiber transmitter ……………………1 pcs
HDMI extender Fiber receiver ……………………… 1 pcs
LC SFP Module………………………………........... 2 pcs
USB data cable .......……………………………….... 1 pcs
Power adapter ……………………………….... 2 pcs
User manual …………………………………..1 pcs

Questions about this item

How do I connect the transmitter and receiver over LC fiber and which step is often missed?

Connect one LC single-mode or multi-mode fiber between the two included SFP modules, plug each module into its unit, attach the two power adapters, then link source to transmitter HDMI IN and remote display to receiver HDMI OUT; the step often missed is inserting both SFP modules before powering on.

What maintenance will the fiber link need over time?

The LC connectors and SFP modules require only occasional cleaning with a lint-free wipe and isopropyl alcohol if dust builds up; the DC 12V/1A power adapters should be replaced if voltage drifts or the units become unstable.

What limit appears first during continuous 4K@60Hz operation?

The 10Gbps transfer rate and HDMI 2.0b/HDCP 2.2 compliance set the bandwidth ceiling, so sustained 4K@60Hz at 3840x2160 is the maximum supported signal before any degradation.
