Jancy Magnetic Drill Press Kit 101 120V 450 RPM 31.7 lb
A 120 V magnetic drill press kit weighing 31.7 lb with 450 RPM no-load speed and 11.5 A draw
- 120 V AC operation powers the motor for reliable shop use
- 450 RPM no-load speed delivers controlled drilling in steel
- 1-1/2 inch steel capacity handles substantial workpieces
- 2,000 lb magnetic hold keeps the base secure during cuts
- 7 lb weight allows one-person positioning on site
Magnetic Drill Press Kit 101
The Jancy Magnetic Drill Press Kit 101 is a 120V AC electro-magnetic drill built for steel fabrication. It delivers a 1-3/4 hp motor running at 450 RPM no-load speed. The unit weighs 31.7 lb and draws 11.5 A during operation. It suits structural steel and machine-shop environments where portable hole-making is required.
Installation notes
Secure the electro-magnet base on clean, flat ferrous material at least 16 gauge thick to develop the rated 2,000 lb holding force. The 3/4 in spindle taper accepts standard tooling directly. A common error is mounting on painted, curved or thin stock where magnetic adhesion drops below safe levels. The kit ships with a 9/16 in drill travel and 1-7/8 in drill-point-to-base centre distance.
Capacity and headroom
Maximum steel drilling capacity is 1-1/2 in diameter with a 1/2 in tap size limit. The 9/16 in drill travel and 1-7/8 in throat depth restrict reach on deep or wide workpieces. The 17-3/4 in overall height and 9-3/8 in length limit use inside tight enclosures. The non-reversible motor prevents reverse tapping cycles.
Highlights
- 120 V AC operation powers the motor for reliable shop use
- 450 RPM no-load speed delivers controlled drilling in steel
- 1-1/2 inch steel capacity handles substantial workpieces
- 2,000 lb magnetic hold keeps the base secure during cuts
- 7 lb weight allows one-person positioning on site
Specifications
| Brand | SLUGGER BY FEIN |
|---|
Questions about this item
How can I confirm the magnetic drill press is operating correctly after setup?
Verify the motor runs at 450 RPM no-load speed and draws 11.5 A on 120V AC; the electro-magnet should hold with 2,000 lb drill-point pressure.
What comes in the Jancy 101 kit and what must be purchased separately?
The kit includes the magnetic drill press unit; cutting tools, coolant and safety accessories are sold separately.
Which capacity version of the 101 magnetic drill press should I choose?
The 101 model offers 1 1/2 in steel capacity, 2 9/16 in drill travel and 1/2 in tap capacity — select it when those limits match the work.
