Black 2U aluminium rackmount chassis with six trayless 3.5-inch hot-swap bays

iStarUSA Inc.

iStarUSA Inc. D-260HN 2U rackmount server chassis 6×3.5″ hotswap bays

SKU CH-MHEH-VY1WB MPN D-260HN

2U rackmount chassis holds six trayless hot-swap 3.5″ bays plus two internal 2.5″ bays with front USB 3.0 ports

  • Chassis TypeRackmount
  • Form Factor2U
  • ColorBlack
  • Case MaterialAluminum
  • Motherboard Compatibility9.6 x 9.6 (microATX, mini-ITX)
  • Hot-Swap Drive Bays3.5": 6
  • Six trayless 3.5" hot-swap bays for rapid drive changes
  • Two internal 2.5" bays add extra storage capacity
  • Four low-profile expansion slots fit specialised add-in cards
  • Front USB 3.0 ports give quick peripheral access
  • Aluminium front panel and SGCC chassis combine light weight with rigidity

Compact 2U rackmount for microATX builds

The iStarUSA D-260HN is a 2U aluminium chassis that fits microATX or mini-ITX boards measuring 9.6 x 9.6 inches. Six trayless 3.5-inch bays at the front accept SAS or SATA drives with 6.0 Gb/s support. Two internal 2.5-inch slots add extra storage. Four low-profile expansion slots and two front USB 3.0 ports complete the package.

Replaces larger 4U towers or non-hotswap cases

Move to this chassis when you need hot-swap access to six drives in half the rack height. The jump is worth it if your current case forces a shutdown to swap disks or lacks front USB 3.0. It also suits builders converting a desktop tower to rackmount without changing the motherboard or power supply.

Check board size, PSU type and rail depth

Verify your board is microATX or mini-ITX at 9.6 x 9.6 inches; full-size ATX will not fit. Confirm the power supply is a standard PS2 or PS3 unit, as redundant or proprietary units are not supported. Measure rack rail depth against the 20.66-inch chassis length and ensure low-profile cards meet the four-slot limit.

Highlights

  • Six trayless 3.5" hot-swap bays for rapid drive changes
  • Two internal 2.5" bays add extra storage capacity
  • Four low-profile expansion slots fit specialised add-in cards
  • Front USB 3.0 ports give quick peripheral access
  • Aluminium front panel and SGCC chassis combine light weight with rigidity

Specifications

BrandiStarUSA
ModelD-260HN
Chassis TypeRackmount
Form Factor2U
ColorBlack
Case MaterialAluminum
Motherboard Compatibility9.6 x 9.6 (microATX, mini-ITX)
Hot-Swap Drive Bays3.5": 6
Internal 2.5" Drive Bays2
Expansion Slots4 (Low profile)
Front Ports2x USB 3.0
80mm Fans1
Features6x Hotswappable and Trayless 3.5" Drive Bays
Rackmount or Desktop Convertible
Compatible with PS2 and PS3 Power Supply
Aluminum Sleek Front Panel
Front 2x USB 3.0 ports
Power & HDD Indicators in the Front
Dimensions3.48" x 18.98" x 20.66"
Weight19.00lbs
Shipping weight7.85 kg
Package size612 × 594 × 216 mm

Questions about this item

Will the 2U chassis fit a 9.6 x 9.6 microATX board and leave room for four low-profile cards?

The 2U rackmount frame accepts microATX or mini-ITX boards up to 9.6 x 9.6 inches and provides four low-profile expansion slots at the rear.

Do the six 3.5-inch trayless bays need any caddies or tools to swap SAS or SATA drives?

No caddies or tools are required; each bay is trayless and supports hot-swap of 3.5-inch SAS I/II and SATA I/II/III drives up to 6.0 Gb/s.

What cooling and power items must be added before the system runs?

You must supply a standard ATX PS2 or PS3 power supply; the chassis includes one 80 mm fan for baseline airflow.
