IOGEAR GUS432CA1KIT 2x4 USB 3.0 KVM Switch with USB-C Adapter
Shares four USB 3.0 peripherals between two computers with push-button switching and an included USB-C adapter
- TypeUSB
- PC Connectors2 x USB 3.0 Type B
- Console Connectors4 x USB 3.0 Type A USB Type Micro B (optional)
- PC SelectionRemote control selector button
- LED IndicatorsPort Status: White
- Temperature0ºC to 40ºC(32ºF to 104ºF)
- Share 4 USB 3.0 peripherals between 2 computers with one switch
- Connect a USB-C PC or Mac using the included USB-A to USB-C adapter
- Switch active computers instantly with a push-button selector
- Transfer data at up to 5 Gbps with USB 3.0 SuperSpeed
- White LED indicator shows which computer is currently active
USB 3.0 KVM Switch for Two Computers
The IOGEAR GUS432CA1KIT shares four USB 3.0 peripherals between two host computers using a push-button selector. An included USB-A to USB-C adapter cable allows a USB-C equipped PC or Mac to connect as one of the hosts. Data transfers run at up to 5 Gbps per port. White LEDs show the active computer.
Check Your Host Ports and Cable Reach
Verify each computer provides a USB 3.0 Type B or USB-C port for the upstream link; the switch requires two such connections. The adapter cable converts one Type A output to USB-C for newer laptops. Ensure the combined cable lengths from both hosts to the switch fit your desk layout. The unit operates from 0°C to 40°C.
Desktop Peripheral Hub with Shared Access
Four Type A ports on the front accept keyboards, mice, drives or other USB 3.0 devices that both computers can use one at a time. The switch draws 1.43 W at 5 V from the host connection, so no external power brick is needed. Its 3.75 by 3.75 by 1.06 inch footprint suits a crowded desk. Buyers needing more than two hosts or more than four shared devices should look elsewhere.
Highlights
- Share 4 USB 3.0 peripherals between 2 computers with one switch
- Connect a USB-C PC or Mac using the included USB-A to USB-C adapter
- Switch active computers instantly with a push-button selector
- Transfer data at up to 5 Gbps with USB 3.0 SuperSpeed
- White LED indicator shows which computer is currently active
Specifications
| Brand | IOGEAR |
|---|---|
| Model | GUS432CA1KIT |
| Type | USB |
| PC Connectors | 2 x USB 3.0 Type B |
| Console Connectors | 4 x USB 3.0 Type A USB Type Micro B (optional) |
| PC Selection | Remote control selector button |
| LED Indicators | Port Status: White |
| Temperature | 0ºC to 40ºC(32ºF to 104ºF) |
| Humidity | 0% to 80%,Non-Condensing |
| Power Features | Power Consumption: DC 5V, 1.43W |
| Features | Share 4 separate USB 3.0 devices between 2 computers Connect a USB-C PC or Mac via the included USB-A to USB-C adapter cable. Easy push-button switching between computers Supports data transfer rates of up to 5 Gbps LED indicates which computer is active Features over-current protection Connect or remove computers via hot-plugging without powering down Connect optional Micro USB cable to support additional power (up to 2.5W via USB 2.0 Port, up to 4.5W via USB 3.0 Port) |
| Dimensions | 3.75" x 3.75" x 1.06" |
| Weight | 0.27 lbs. |
| Package Contents | 1 x 2x4 USB 3.0 Peripheral Sharing Switch 1 x Quick Start Guide 1 x Warranty Card 1 x USB-C to A Adapter (G2LU3CAF10-SIL) |
| Shipping weight | 0.66 kg |
| Package size | 257 × 185 × 119 mm |
Questions about this item
What cables and accessories come with the IOGEAR GUS432CA1KIT and do I need to buy any separately?
The box includes the 2x4 USB 3.0 peripheral sharing switch, a USB-C to USB-A adapter cable (G2LU3CAF10-SIL), a quick start guide and a warranty card. Two USB 3.0 Type B cables to connect your computers are not included and must be purchased separately.
Should I choose this model if I have two computers and four USB 3.0 peripherals to share?
Yes, this switch is built for exactly that layout: two upstream USB 3.0 Type B ports for the computers and four downstream USB 3.0 Type A ports for the peripherals, with an included USB-C adapter so a USB-C laptop can also be one of the two computers.
What does the 5 Gbps headline speed mean when the switch is connected to my PC and devices?
It means each shared USB 3.0 device can transfer data at up to 5 Gbps, the full USB 3.0 rate, provided the host computer, the cable and the peripheral all support USB 3.0; the switch itself does not reduce that maximum throughput.
