IOGEAR
IOGEAR GCS1794 4-Port HDMI KVMP Switch with Audio
Switches a single HDMI display, keyboard and mouse between four computers with digital audio up to 1920 x 1200 resolution
- TypeHDMI, USB
- PC ConnectorsKeyboard & Mouse 4 x USB Type B Female Monitor 4 x HDMI Type
- Console ConnectorsKeyboard 1 x USB Type A Female Mouse 1 x USB Type A Female M
- Computer Connections4 Ports
- Video Resolution1920 x 1200
- AutoScan Interval1-99 seconds
- Control four computers from one console using 4 HDMI and USB ports
- Enjoy crisp visuals up to 1920 x 1200 resolution across connected displays
- Integrated audio switching handles speakers and microphone for multimedia use
- Automate monitoring with adjustable AutoScan interval from 1 to 99 seconds
- Compact 10.25 x 1.63 x 3.00 inch design fits neatly on any desk
Four-computer HDMI KVMP switch
The IOGEAR GCS1794 lets one keyboard, mouse and HDMI display control four USB-equipped computers. It adds stereo audio and microphone switching so multimedia peripherals stay shared across every connected system.
Sustained switching with autoscan
Front-panel buttons or hot-key commands change the active port instantly while the autoscan timer cycles through inputs at intervals from 1 to 99 seconds. LED indicators show which USB peripherals and which computer link are live at any moment.
Metal chassis with front and rear audio jacks
The unit measures 10.25 by 1.63 by 3.00 inches and weighs 4.72 lbs, providing a stable desktop presence. Console side duplicates the green audio jack on both front and rear panels for convenient headphone or speaker access.
Highlights
- Control four computers from one console using 4 HDMI and USB ports
- Enjoy crisp visuals up to 1920 x 1200 resolution across connected displays
- Integrated audio switching handles speakers and microphone for multimedia use
- Automate monitoring with adjustable AutoScan interval from 1 to 99 seconds
- Compact 10.25 x 1.63 x 3.00 inch design fits neatly on any desk
Specifications
| Brand | IOGEAR |
|---|---|
| Model | GCS1794 |
| Type | HDMI, USB |
| PC Connectors | Keyboard & Mouse 4 x USB Type B Female Monitor 4 x HDMI Type A Female Audio 4 x Mini Stereo Jack Female (Green) Microphone 4 x Mini Stereo Jack Female (Pink) |
| Console Connectors | Keyboard 1 x USB Type A Female Mouse 1 x USB Type A Female Monitor 1 x HDMI Type A Female Audio 2 x Mini Stereo Jack Female (Green; 1 x Front Panel, 1 x Rear Panel); through HDMI Type A Female if CPU's audio is sending through HDMI port along with Video Microphone 2 x Mini Stereo Jack Female (Pink; 1 x Front Panel, 1 x Rear Panel) Flash ROM Upgrade 1 x 4-conductor 3.5mm Jack (Black) |
| Computer Connections | 4 Ports |
| Video Resolution | 1920 x 1200 |
| AutoScan Interval | 1-99 seconds |
| LED Indicators | USB Peripherals 4 (Green) On Line 4 (Orange) |
| Audio Features | with Audio |
| Power Features | 5.3V |
| USB Features | with USB support |
| Features | Share an HDMI HDTV or Display, keyboard, mouse with digital surround sound between 4 USB, HDMI computers and devices Video Resolutions: 480i, 480p, 720i, 720p, 1080i and 1080p Maximum video resolution: 1920 x 1200 2 x USB 2.0 peripherals sharing ports Dolby True HD and DTS HD Master Audio Support through HDMI Multi-platform OS support - Windows?, Mac, Sun Solaris, Linux HDMI 1.3b and HDCP compliant IOGEAR's Display Emulation Technology reads and remembers the monitor's parameters (EDID) so there is no delay or change of video resolution when switching between, or booting computers Po |
| Dimensions | 10.25" x 1.63" x 3.00" |
| Weight | 4.72 lbs. |
| Shipping weight | 2.36 kg |
| Package size | 330 × 216 × 102 mm |
Questions about this item
How much heat or fan noise does the GCS1794 produce when left on all day?
The unit draws 5.3 V DC from an external adapter and has no internal fan, so it runs silently with minimal heat buildup during continuous operation.
Which cables must I already have to connect four computers to the GCS1794?
Each computer requires an HDMI cable for video and a USB Type-B to Type-A cable for keyboard and mouse; stereo and microphone cables use mini-jack connectors.
Will the GCS1794 work with an older PC that only outputs 1080p over HDMI?
Yes, the switch supports 1080p and lower resolutions such as 720p and 480p, so legacy HDMI sources display correctly at their native resolution.
