Compact silver box with front push buttons and rear DVI USB audio ports

IOGEAR

IOGEAR GCS1102 2-Port DVI KVM Switch

SKU CH-ZHT4-P5WBJ MPN GCS1102

Control two USB DVI computers from one console with 1920 x 1200 resolution, audio, microphone and USB 2.0 peripheral sharing

  • TypeDVI, USB
  • PC ConnectorsMonitor: 2 x DVI-I ports (female) Microphone: 2 x Microphone
  • Console ConnectorsMouse 1 x USB Type A socket Keyboard 1 x USB Type A socket M
  • Computer Connections2 Ports
  • Monitor Connections1 Port
  • Video ResolutionUp to 1920 x 1200; DDC2B
  • One console manages two USB DVI computers
  • Single-link DVI up to 1920 x 1200 at 60 Hz with DDC2B
  • Built-in USB 2.0 hub shares peripherals across both systems
  • Auto-scan switches automatically at intervals from 1 to 99 seconds
  • Front-panel buttons and hotkey commands select the active PC

2-Port DVI KVM Switch for Dual Systems

The IOGEAR GCS1102 is a new KVM switch that lets one DVI monitor, USB keyboard, USB mouse, microphone and stereo headphones control two separate computers. It includes a built-in two-port USB 2.0 hub so shared peripherals stay connected while you switch between machines.

Suited for dual-PC workstations lacking

This unit fits users who need to operate two DVI-equipped computers from a single desk without unplugging cables. It does not serve setups that require DisplayPort, HDMI or resolutions above 1920 x 1200, nor does it support more than two connected systems.

Maximum video resolution 1920 x 1200 at 60 Hz

The switch passes single-link DVI signals up to 1920 x 1200 at 60 Hz with DDC2B support, so the attached monitor must accept that resolution and refresh rate. If your displays need higher pixel counts or different video interfaces, this model will not meet the requirement.

Highlights

  • One console manages two USB DVI computers
  • Single-link DVI up to 1920 x 1200 at 60 Hz with DDC2B
  • Built-in USB 2.0 hub shares peripherals across both systems
  • Auto-scan switches automatically at intervals from 1 to 99 seconds
  • Front-panel buttons and hotkey commands select the active PC

Specifications

BrandIOGEAR
ModelGCS1102
TypeDVI, USB
PC ConnectorsMonitor: 2 x DVI-I ports (female)
Microphone: 2 x Microphone jack
Audio: 2 x Stereo earphone jack
Keyboard & Mouse: 2 x USB Type B sockets
Console ConnectorsMouse 1 x USB Type A socket
Keyboard 1 x USB Type A socket
Monitor 1 x DVI-I (female) port
Microphone 1 x Microphone jack
Audio 1 x Stereo earphone jack
Computer Connections2 Ports
Monitor Connections1 Port
Video ResolutionUp to 1920 x 1200; DDC2B
PC SelectionFront Panel Switches; Hotkey
AutoScan Interval1-99 secs (default: 5 secs)
Bandwidth10.50
LED IndicatorsSelected: 2 x Orange
On Line: 2 x Orange
USB Peripherals: 2 x Green
FeaturesOne console controls 2 USB DVI computers
Single link DVI resolution up to 1920 x 1200 @ 60Hz; DDC2B
2-port USB 2.0 hub for peripherals sharing
IOGEAR's Display Emulation Technology reads and remembers the monitor's parameters (EDID) so there is no delay or change of video resolution when switching between, or booting computers
Independent (Asynchronous) Hotkey switching between KVM focus, USB peripherals, and audio ports
2.1 Stereo audio and microphone support
Computer selection via front panel switches or hotkeys
LED display for easy status monitoring
Auto Scan Mode - For monitoring
Dimensions8.5" x 2" x 3.25"
Weight4.34 lbs.
Shipping weight1.72 kg
Package size272 × 221 × 99 mm

Questions about this item

Should I pick the GCS1102 or a different capacity for two DVI computers?

The GCS1102 is the two-port model that lets one DVI monitor, USB keyboard, mouse, speakers and microphone control two USB DVI computers and shares two USB 2.0 peripherals.

What does the 1920 x 1200 @ 60Hz figure mean once the switch is in my rack?

It means each connected computer can drive a single-link DVI display at up to 1920 x 1200 pixels at 60 Hz through the switch without signal degradation.

Which video interface and standard does the GCS1102 use, and what does it cap in practice?

It uses DVI-I single-link with DDC2B, capping the video path at 1920 x 1200 @ 60 Hz and 10.50 bandwidth while passing EDID data to both computers.
