IOGEAR GCE500U USB VGA KVM Console Extender 500 ft 1920x1200 60Hz
Extends a VGA monitor, USB keyboard and mouse up to 500 ft over CAT5e cable with 1920 x 1200 resolution at 60Hz
- TypeD-Sub, USB
- PC ConnectorsKeyboard, Mouse, and Monitor: 1 x SPHD-17 Female (Green) Uni
- Console ConnectorsMonitor: 1 x HDB-15 Female Keyboard: 1 x USB Type A Female M
- Computer Connections1 Port
- Video ResolutionUp to 1920 x 1200 @ 60Hz
- LED IndicatorsLocal: 1 x Local; 1 x Remote Remote: 1 x Remote; 1 x Link
- Extends VGA, USB keyboard and mouse up to 500 ft via CAT5e/6
- Auto Signal Compensation removes the need for manual DIP-switch setup
- Supports 1920 x 1200 resolution at 60 Hz for clear remote video
- Single-port design connects one computer to a remote console
- Compact 5 x 1 x 3.375 in unit weighs only 1.41 lbs
USB VGA KVM Console Extender 500 ft
The IOGEAR GCE500U extends a VGA monitor, USB keyboard, and USB mouse up to 500 ft from a computer or USB KVM switch using a single CAT5e or CAT6 cable. It connects the local unit via an SPHD-17 interface and the remote unit through HDB-15 and USB Type-A ports. This suits server rooms, industrial floors, or digital-signage installs where the operator must sit far from the host.
1920 x 1200 @ 60Hz video headroom
The extender delivers up to 1920 x 1200 resolution at 60 Hz across the full 500 ft link. Auto Signal Compensation adjusts the video automatically so no DIP-switch configuration is required. Beyond that distance or above that resolution the signal will degrade, and the unit does not support higher refresh rates or digital video formats.
CAT5e/6 copper distance limit
The RJ45 link is bound by the electrical characteristics of CAT5e or CAT6 copper cabling, so the 500 ft ceiling is a hard physical limit. The extender adds no signal regeneration beyond that point, and it cannot operate over fibre, wireless, or IP networks. Buyers needing longer runs or multi-computer switching must choose a different architecture.
Highlights
- Extends VGA, USB keyboard and mouse up to 500 ft via CAT5e/6
- Auto Signal Compensation removes the need for manual DIP-switch setup
- Supports 1920 x 1200 resolution at 60 Hz for clear remote video
- Single-port design connects one computer to a remote console
- Compact 5 x 1 x 3.375 in unit weighs only 1.41 lbs
Specifications
| Brand | IOGEAR |
|---|---|
| Model | GCE500U |
| Type | D-Sub, USB |
| PC Connectors | Keyboard, Mouse, and Monitor: 1 x SPHD-17 Female (Green) Unit to Unit Connectors: 1 x RJ45 Female Power Connections: 1 x DC Jack Function Keys: 1 x Operating Mode Pushbutton |
| Console Connectors | Monitor: 1 x HDB-15 Female Keyboard: 1 x USB Type A Female Mouse: 1 x USB Type A Female |
| Computer Connections | 1 Port |
| Video Resolution | Up to 1920 x 1200 @ 60Hz |
| LED Indicators | Local: 1 x Local; 1 x Remote Remote: 1 x Remote; 1 x Link |
| Humidity | 0~80% RH; Non-condensing |
| Features | Extend your KVM console (VGA monitor, USB keyboard & mouse) connection up to 500 ft. via CAT5e cables Auto Signal Compensation (ASC) helps make installation easy, with no need to configure DIP switches Built-in Application-Specific Integrated Circuit (ASIC) for greater reliability and compatibility Dual Console Operation - Control your system from either the local or remote console Built-in 8KV ESD protection and 2KV surge protection Maximum video resolution up to 1920 x 1200 @ 60Hz (100 ft. - 30m); 1600 x 1200 @ 60HZ (330 ft. - 100m); 1280 x 1024 @ 60Hz (500 ft. - 150m) USB over-cur |
| Dimensions | 5" x 1" x 3.375" |
| Weight | 1.41 lbs. |
| Shipping weight | 1.47 kg |
| Package size | 284 × 170 × 102 mm |
Questions about this item
Will my existing USB keyboard and mouse plug directly into the HDB-15 and USB Type A ports on the remote unit?
Yes — the remote unit provides one HDB-15 female for the VGA monitor and two USB Type A females for keyboard and mouse, so standard USB peripherals connect without adapters.
How can I confirm the link is active and the video signal is stable after I run the CAT5e cable?
The remote unit shows a Link LED and a Remote LED; when both are lit the extender has established a connection and is passing 1920 x 1200 @ 60 Hz video.
Does the package include the CAT5e cable needed to reach 500 ft, or must I buy it separately?
The box contains the local and remote units, a power adapter, and an SPHD-17 cable for the computer side; the CAT5e/6 cable for the 500 ft run is not included.
