Compact desktop metal switch with eight RJ45 ports and one SFP+ uplink

Intellinet Network Solutions

Intellinet Network Solutions IPS-08-2.5G01-100W 9-Port 2.5G PoE++ Switch

SKU CH-11RN-ESFF1

Unmanaged desktop switch with eight 2.5 Gbps PoE++ ports, 100 W budget, and one SFP+ uplink

  • Switch TypeUnmanaged PoE++ Switch
  • FormatDesktop
  • StandardsIEEE 802.3ab, IEEE 802.3bz, IEEE 802.3af, IEEE 802.3at, IEEE
  • Network Management TypeUnmanaged
  • Uplink Ports1
  • Uplink InterfaceSFP
  • Powers eight devices with 100 W total budget
  • 5 Gbps RJ45 ports with 10/100/1000 Mbps backward compatibility
  • 10 Gbps SFP+ uplink slot for high-speed aggregation
  • 60 W PoE++ per port with short-circuit and overload protection
  • Fanless metal chassis runs silently on the desktop

9-Port 2.5G Unmanaged PoE++ Switch

The Intellinet IPS-08-2.5G01-100W is an unmanaged desktop switch with eight 2.5 Gbps RJ45 ports and one SFP+ uplink slot. It delivers both data and power to connected devices without requiring configuration. The fanless metal housing ensures silent operation in office or home environments.

100 W PoE++ budget with up to 60 W per port

The switch provides a total power budget of 100 watts across all eight PoE++ ports, with each port capable of supplying up to 60 watts. This supports IEEE 802.3bt devices such as PTZ cameras, thin clients and high-power wireless access points. Built-in protection guards against short circuit, overload and high-voltage events.

Suits deployments needing multi-gigabit PoE

Ideal for installing Wi-Fi 6 access points, VoIP phones or surveillance cameras where 2.5 Gbps bandwidth and up to 60 W per device are required. Not suited for networks that require managed features such as VLANs, QoS or remote monitoring. Buyers needing more than eight powered ports or a higher total power budget should consider a larger chassis.

Highlights

  • Powers eight devices with 100 W total budget
  • 5 Gbps RJ45 ports with 10/100/1000 Mbps backward compatibility
  • 10 Gbps SFP+ uplink slot for high-speed aggregation
  • 60 W PoE++ per port with short-circuit and overload protection
  • Fanless metal chassis runs silently on the desktop

Specifications

BrandIntellinet
ModelIPS-08-2.5G01-100W
Switch TypeUnmanaged PoE++ Switch
FormatDesktop
StandardsIEEE 802.3ab, IEEE 802.3bz, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Network Management TypeUnmanaged
Uplink Ports1
Uplink InterfaceSFP
Uplink SpeedSFP+
Primary Port Count8
Primary Ports8 x RJ45 + 1 x SFP
Primary Port Speed2.5 Gbps
Primary Port TypeRJ45
MAC Address Table4K
Switching MethodStore and Forward
Jumbo Frames12KB
Packet Forwarding Rate44.14 Mpps
Buffer Memory1MB
PoEYes
StackableNo
SNMPNo
QoSNo
LACPNo
Layer2
Port MirroringNo
Module SupportYes
TopologyStar
FanFanless
PoE Ports8 x PoE
PoE Power Budget100W
Power100~240VAC, 50/60Hz
Max Power Consumption120W
Dimensions4.13 x 9.45 x 1.06 in.
Weight1.52 lbs.
CertificationFCC, CE, RoHS, REACH, UKCA
Temperature0°C to 40°C (32°F to 104°F)
Humidity10% - 90%, Non-condensing
Package ContentsPower adapter, Instructions

Questions about this item

What does the 2.5 Gbps port speed mean for devices connected to this switch?

Each of the eight RJ45 ports runs at 2.5 Gbps, so Wi-Fi 6 access points and other multi-gig devices can pass traffic faster than 1 Gbps links allow while still working with 10/100/1000 Mbps gear.

How does the SFP+ uplink port limit real-world throughput?

The single SFP+ slot accepts 10G modules for a 10 Gbps uplink, or standard 1G SFP transceivers if 10G is not yet deployed, giving a 10 Gbps ceiling when a 10G module is fitted.

What physical space and mounting does this desktop switch need?

The fanless metal chassis sits on a desk or shelf; no rack ears or stacking hardware are included, so only a flat surface and a power outlet are required.
