Silver metal rack-mount switch, 24 front RJ45 ports, two SFP slots, 19-inch brackets

Intellinet Network Solutions

Intellinet Network Solutions 560559 24-Port Gigabit PoE+ Web-Managed Switch with 2 SFP Ports

SKU CH-FP9W-ENPXS MPN 560559

A 24-port Gigabit PoE+ web-managed switch with 2 SFP ports, self-healing PD monitoring and up to 30 W per port

  • FormatRack-mountable Desktop
  • Network Management TypeManaged
  • Primary Port Speed10/100/1000Base-T
  • Weight6.83 lb
  • Package ContentsPackage Contents: 24-Port PoE Web-Managed Gigabit Ethernet S
  • CaseMetal Case
  • Powers 24 devices over existing cables saving installation cost
  • Self-healing PDM restarts unresponsive PoE devices automatically
  • Two SFP slots add fibre uplinks for longer runs
  • 30 W per port supports cameras phones and access points
  • Web-managed interface simplifies VLAN QoS and port control

24-Port Gigabit PoE+ Switch for Rack Installations

This 24-port Gigabit switch delivers both data and power over standard Cat5e or Cat6 cables to PoE-compatible devices. It suits installers deploying wireless access points, VoIP phones or IP cameras where separate power wiring is impractical. The unit mounts in a 19-inch rack and includes all necessary brackets. Web-based management provides configuration access without dedicated software.

Fanless Metal Chassis with 30 W Per-Port Budget

A metal case dissipates heat without internal fans, so the switch runs silently in office or server-room environments. Each of the 24 RJ45 ports supplies up to 30 watts under IEEE 802.3at/af, while auto-sensing negotiates 10, 100 or 1000 Mbps links automatically. Total power draw scales with the number of active powered devices connected.

Self-Healing PD Monitor and Dual SFP Uplinks

The Powered Device Monitor watches every PoE port and power-cycles any endpoint that stops sending traffic, restoring cameras or access points without a site visit. Two SFP slots accept standard GBIC modules for fibre uplinks to a core switch. Domotz cloud-management compatibility is available after a firmware upgrade, and the bundle supplies rack brackets, a power cable and a user manual.

Highlights

  • Powers 24 devices over existing cables saving installation cost
  • Self-healing PDM restarts unresponsive PoE devices automatically
  • Two SFP slots add fibre uplinks for longer runs
  • 30 W per port supports cameras phones and access points
  • Web-managed interface simplifies VLAN QoS and port control

Specifications

BrandIntellinet
Model560559
FormatRack-mountable
Desktop
Network Management TypeManaged
Primary Port Speed10/100/1000Base-T
Weight6.83 lb
Package ContentsPackage Contents:
24-Port PoE Web-Managed Gigabit Ethernet Switch with 2 SFP Ports
19" Rackmount Brackets
Power Cable
User Manual
CaseMetal Case
Class24 Port Gigabit PoE
Shipping weight4.54 kg
Package size439 × 221 × 43 mm

Questions about this item

How do I rack-mount the 560559 and what step is often missed?

Attach the included 19-inch rackmount brackets to the metal case, secure the switch in the rack, connect the power cable, then enable the Powered Device Monitor in the web interface so the self-healing PoE watchdog actually restarts unresponsive devices.

What maintenance or replacement will the 560559 need over time?

The switch has no user-replaceable fans or power modules; plan on periodic firmware updates for Domotz cloud compatibility and replace any SFP transceivers if a fibre link fails.

What limit appears first when all 24 PoE+ ports run at full load continuously?

The 30-watt per-port ceiling is reached first; each port stops delivering power above 30 watts even if the total budget has headroom.
