Silver metal rackmount media converter with RJ45 and SC fiber ports

Intellinet Network Solutions

Intellinet Network Solutions 545068 Gigabit WDM Bi-Directional Media Converter 20 km

SKU CH-1JGJ-0NGN9

Converts 10/100/1000 Mbps copper to single-mode fiber over 20 km using one strand with WDM wavelengths

  • FormatRackmount
  • Primary Port Speed1000Base-T 1000Base-LX
  • Extends network reach up to 20 km using single-mode fiber
  • Doubles fiber capacity with WDM on one strand at 1550/1310 nm
  • Connects copper and fiber segments at 10/100/1000 Mbps
  • Auto MDI/MDI-X RJ45 simplifies cabling up to 100 m
  • Status LEDs provide instant link and activity monitoring

What This Converter Does

The Intellinet 545068 is a Gigabit WDM bi-directional media converter that links copper Ethernet to single-mode fiber. It is built for network managers who need to extend a 10/100/1000 Mbps segment over long distances without laying a second fiber strand. The rackmount unit fits standard cabinets and operates transparently on the existing network.

The Distance That Decides Fit

This model reaches 20 km (12.4 miles) over a single fiber strand using 1550 nm receive and 1310 nm transmit wavelengths. That specific reach and wavelength pairing determines whether the link matches your site-to-site span. If the run is shorter or the paired unit uses different wavelengths, this converter will not establish a link.

The Paired Unit Requirement

The converter must be used with the matching 545075 model on the far end to complete the bi-directional path. Without that counterpart, the single-strand WDM connection cannot function. The box includes status LEDs for link monitoring and an RJ45 port with Auto MDI/MDI-X, but no additional cables or management software are supplied.

Highlights

  • Extends network reach up to 20 km using single-mode fiber
  • Doubles fiber capacity with WDM on one strand at 1550/1310 nm
  • Connects copper and fiber segments at 10/100/1000 Mbps
  • Auto MDI/MDI-X RJ45 simplifies cabling up to 100 m
  • Status LEDs provide instant link and activity monitoring

Specifications

BrandIntellinet Network Solutions
FormatRackmount
Primary Port Speed1000Base-T 1000Base-LX
Model545068

Questions about this item

What distance can the fiber link actually cover when this converter is installed in a live network?

The single-mode SC port is rated for up to 20 km (12.4 miles) of fiber between this converter and its paired unit.

Which wavelength pair does the single-fiber interface use and what throughput does it support?

It receives at 1550 nm and transmits at 1310 nm, carrying 10/100/1000 Mbps Ethernet over one strand.

What rack space and companion unit does this model require for mounting and operation?

It is a rackmount device and must be paired with the matching model 545075 converter at the far end.
