Small rectangular SFP module with silver metal housing and black SC fiber port

Intellinet Network Solutions

Intellinet Network Solutions 510547 SFP transceiver 100Base-FX SC 20 km RX1550 TX1310

SKU CH-ERVY-Q8FS6 MPN 510547

Single-mode SFP transceiver extends Fast Ethernet links to 20 km over one fiber strand using 1550 nm receive and 1310 nm transmit wavelengths

  • Device TypeTransceiver
  • Wavelength1550 nm 1310 nm
  • ProtocolsFast Ethernet
  • Ports10/100Base-TX 100Base-FX
  • Max Distance12.43 Mile
  • Power AdapterRack-mountable Desktop External Standalone Wall Mountable
  • Single-fiber WDM link reaches 20 km
  • 100 Mbps Fast Ethernet over single-mode SC
  • RX 1550 nm / TX 1310 nm wavelengths
  • Pairs with converter 510530 for bi-directional operation
  • RJ45 auto MDI/MDI-X up to 100 m

100Base-FX SFP transceiver for single-mode fibre

The Intellinet 510547 is a Fast Ethernet SFP transceiver that connects a 10/100Base-TX copper port to a 100Base-FX single-mode fibre port. It uses wavelength-division multiplexing on one fibre strand, receiving at 1550 nm and transmitting at 1310 nm. The module is designed for network managers extending copper segments over fibre.

Sustained 100 Mbps over 20 km single-mode fibre

The transceiver maintains a 100 Mbps data rate across distances up to 20 km (12.4 miles) on single-mode fibre with SC connectors. WDM technology keeps transmit and receive paths separate on the same strand, so the link stays stable without adding a second fibre. The copper RJ45 side supports Auto MDI/MDI-X up to 100 m on Cat5e or better cable.

Replaces a copper-only link when distance exceeds

Deploy this transceiver when a standard copper run cannot reach the remote device and a single fibre strand is available. It must be paired with the matching 510530 media converter on the opposite end to complete the bi-directional link. The jump is worth it when extending a Fast Ethernet segment between buildings or cabinets without trenching new cable.

Highlights

  • Single-fiber WDM link reaches 20 km
  • 100 Mbps Fast Ethernet over single-mode SC
  • RX 1550 nm / TX 1310 nm wavelengths
  • Pairs with converter 510530 for bi-directional operation
  • RJ45 auto MDI/MDI-X up to 100 m

Specifications

BrandIntel
Device TypeTransceiver
Wavelength1550 nm 1310 nm
ProtocolsFast Ethernet
Ports10/100Base-TX 100Base-FX
Max Distance12.43 Mile
Power AdapterRack-mountable Desktop External Standalone Wall Mountable
Shipping weight0.23 kg
Package size231 × 124 × 53 mm

Questions about this item

Does the 100 Mbps link generate noticeable heat or noise when running continuously?

The unit has no moving parts and draws minimal power, so it runs silently and stays cool even during all-day operation.

Which companion device must I already have for this transceiver to function?

It requires the matching Fast Ethernet WDM Bi-Directional Single Mode Media Converter, model 510530, to provide the copper and fiber interfaces.

Will the 100Base-FX SC port at 1310 nm TX / 1550 nm RX interoperate with my existing single-mode fiber plant?

Yes — it uses standard single-mode SC connectors and the industry-standard WDM wavelength pair, so it links directly to compatible single-mode gear over distances up to 20 km.
