Silver 19-inch rackmount switch with 24 front RJ45 ports and 4 combo SFP slots

Intellinet

Intellinet IPS-28GM04-370W 24-Port Gigabit PoE+ Web-Managed Switch

SKU CH-PAGJ-B0SVD

24-port Gigabit PoE+ switch delivers up to 370 W to power IP cameras, access points and VoIP phones while providing four SFP/RJ45 combo uplinks and self-healing PD monitoring

  • Switch Typemanaged
  • FormatRackmount
  • Network Management TypeManaged
  • Uplink Ports24
  • Uplink InterfaceSFP & RJ45
  • Uplink Speed1 Gbps
  • Powers up to 24 PoE devices from a single switch
  • 370 W total budget fuels cameras, APs and VoIP phones
  • Four SFP/RJ45 combo uplinks add 1 Gbps fibre or copper links
  • Self-healing PDM watchdog auto-restarts unresponsive powered devices
  • Web-managed with VLAN, SNMP and Jumbo Frame support

24-Port Gigabit PoE+ Web-Managed Switch

This Intellinet switch delivers data and power to 24 PoE-compatible devices over standard network cables. It suits installers who need to power wireless access points, VoIP phones or IP cameras without separate power supplies. The 370 W budget supports IEEE 802.3at and af PoE+ across every RJ45 port.

Rackmount installation with combo uplinks

The 19-inch rackmount form factor fits standard cabinets and the console port allows direct configuration from a computer. Four combo ports accept either RJ45 copper or SFP fibre modules for flexible uplink choices. Web management adds a browser interface, while Domotz cloud support may require a firmware upgrade before use.

PoE budget and frame limits

The 370 W total PoE budget is shared across all 24 ports, so high-power devices reduce the number of ports that can run simultaneously. Jumbo frames up to 9600 bytes are supported for larger packet handling. The MAC table holds 8K entries and buffer memory is 4 MB, which constrains very large address tables or burst traffic.

Highlights

  • Powers up to 24 PoE devices from a single switch
  • 370 W total budget fuels cameras, APs and VoIP phones
  • Four SFP/RJ45 combo uplinks add 1 Gbps fibre or copper links
  • Self-healing PDM watchdog auto-restarts unresponsive powered devices
  • Web-managed with VLAN, SNMP and Jumbo Frame support

Specifications

BrandIntellinet
ModelIPS-28GM04-370W
Switch Typemanaged
FormatRackmount
Network Management TypeManaged
Uplink Ports24
Uplink InterfaceSFP & RJ45
Uplink Speed1 Gbps
Primary Port Count24
Primary Ports24 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table8K
Switching MethodStore and Forward
VLAN SupportYes
Jumbo Frames9600 bytes
Buffer Memory4MB
ProtocolsCSMA/CD
PoEYes
StackableNo
SNMPYes
QoSYes
LACPYes
Layer2
Layer 2 FeaturesVLAN, QoS, LACP, Port Mirroring, Broadcast Storm control, IGMP Snooping
Port MirroringYes
TopologyStar
Fan2 cooling fans
PoE Ports24
PoE Power Budget370W
Max Power Consumption431W
Dimensions8.19 (L) x 17.32 (W) x 1.73 (H) [in]
Weight10.36 lbs.
Temperature0°C to 45°C (32°F to 113°F)
Humidity10% - 90%, Non-condensing
Package Contents24-Port Gigabit Ethernet PoE+ Web-Managed Switch with 4 Gigabit Combo Base-T/SFP Ports,
Quick Instruction Guide, Power cable, 19" mounting brackets, Rubber feet

Questions about this item

How do I confirm the Self-Healing PDM feature is restarting an unresponsive IP camera after installation?

Check the web management interface for PDM event logs showing power-cycle timestamps on the specific port where the camera is connected.

What cables and SFP modules must I purchase separately to use the four combo uplink ports?

The unit includes a rack-mount kit and console cable; Cat5e or Cat6 patch cords and SFP transceivers for fibre uplinks are not supplied.

Which model should I choose if I need 24 PoE+ ports with a 370 W budget and four Gigabit combo uplinks?

This IPS-28GM04-370W model provides exactly 24 PoE+ ports, 370 W total power, and four combo SFP/RJ45 uplinks in a 19-inch rackmount chassis.
