Green circuit board with four copper RJ-45 ports and metal bracket

Intel

Intel I340-T4 E1G44HT Quad Port RJ-45 x4 Gigabit Network Card

SKU CH-WMAC-PR6J9

Adds four gigabit RJ-45 ports via a PCI-Express 2.0 interface with Intel 82580 controller

  • Speed10/100/1000Mbps
  • ConnectorsRJ-45 x4
  • InterfacePCI-Express
  • Wake On LANYes
  • Four Gigabit RJ-45 ports for dense server connectivity
  • PCIe 2.0 interface scales bandwidth for multi-core workloads
  • Intel 82580 controller integrates four ports on one chip
  • Wake-on-LAN enables remote power management
  • Retail box includes full-height and low-profile brackets

Intel I340-T4 Quad-Port Adapter

The Intel I340-T4 is a PCI Express network adapter that provides four independent RJ-45 Gigabit Ethernet ports from a single expansion slot. It is built for servers and workstations that need to connect to multiple wired networks or segment traffic across separate physical links without adding extra cards.

Replaces multi-card setups for density

A single I340-T4 replaces four single-port adapters, freeing PCIe slots and reducing cabling inside crowded chassis. The upgrade is worth it when a host needs more than two Gigabit links but has limited slot availability or when consolidating management interfaces onto one controller simplifies driver maintenance.

Sustained throughput across four ports

The integrated Intel 82580 controller handles concurrent traffic on all four ports at 1000 Mbps without the bottlenecks seen when multiple discrete adapters share a PCIe Gen 2.0 x4 lane budget. Wake-on-LAN remains active on every port during low-power states, allowing remote management traffic to pass continuously without waking the host processor.

Highlights

  • Four Gigabit RJ-45 ports for dense server connectivity
  • PCIe 2.0 interface scales bandwidth for multi-core workloads
  • Intel 82580 controller integrates four ports on one chip
  • Wake-on-LAN enables remote power management
  • Retail box includes full-height and low-profile brackets

Specifications

BrandIntel
ModelE1G44HT
Speed10/100/1000Mbps
ConnectorsRJ-45 x4
InterfacePCI-Express
Wake On LANYes

Questions about this item

Does the I340-T4 include brackets for both full-height and low-profile slots?

Yes, the retail package contains both full-size and half-size brackets so the card fits standard and low-profile chassis.

What PCI Express generation and lane width does the E1G44HT require for installation?

The adapter uses a PCIe Gen 2.0 x4 slot; insert it fully until the latch clicks and attach the chosen bracket before securing the screw.

Are the four RJ-45 ports on the I340-T4 replaceable if one fails?

The ports are soldered to the board and not user-replaceable; a port failure means replacing the entire adapter.
