Compact alloy thermal camera for Android, 49.5 by 26 by 27.5 mm, 13 mm lens, manual focus

InfiRay

InfiRay T3S Thermal Camera Android 384x288 13mm 25Hz

SKU CH-FZ73-0KPPR

Android thermal imager with 384×288 resolution, 13 mm lens, 25 Hz frame rate and 50 mK sensitivity for PCB and floor-heat inspection

  • TypeThermal Camera
  • FeaturesThermal Camera
  • Android 6.0+ compatibility enables instant mobile thermal imaging
  • 384 x 288 resolution captures detailed heat patterns across PCBs and floors
  • 13 mm lens with manual focus adapts to close or wide inspection scenes
  • 25 Hz frame rate delivers smooth real-time video for moving targets
  • ±3 °C accuracy with manual or automatic correction ensures reliable temperature readings

Android thermal imager for inspection

The InfiRay T3S is a compact thermal camera that plugs into an Android device running version 6.0 or later. It delivers a 384x288 resolution through a 13 mm lens with manual focus. The sensor operates in the 8 to 14 µm spectral band with a 17 µm pixel size and a 25 Hz frame rate.

Plug-in setup with manual focus

Installation is limited to connecting the unit to a compatible Android phone or tablet and launching the supporting app. The manual focus ring requires deliberate adjustment for each working distance, so users must allow time to sharpen the image on site. No additional drivers or external power are needed.

Suits PCB and floor-heat checks

The camera suits technicians who need portable thermal imaging for circuit-board diagnostics, underfloor heating surveys or similar close-range tasks within the -20 to 120 °C measuring range. Buyers who require a higher frame rate, automatic focus, or a wider temperature span should look at other models.

Highlights

  • Android 6.0+ compatibility enables instant mobile thermal imaging
  • 384 x 288 resolution captures detailed heat patterns across PCBs and floors
  • 13 mm lens with manual focus adapts to close or wide inspection scenes
  • 25 Hz frame rate delivers smooth real-time video for moving targets
  • ±3 °C accuracy with manual or automatic correction ensures reliable temperature readings

Specifications

BrandInfiRay
TypeThermal Camera
FeaturesThermal Camera

Questions about this item

How can I confirm the T3S is capturing 384x288 thermal frames at 25 Hz on my Android phone?

Open the companion app and verify the live preview shows smooth 25 Hz motion with the 384x288 resolution label displayed in the settings overlay.

What does the box contain and which cables or adapters must I source separately?

The package includes the T3S camera with its 13 mm lens and alloy body; you only need a compatible Android 6.0+ device with a USB-C or micro-USB port — no extra cables are bundled.

Which T3S variant should I pick for PCB inspection versus under-floor heating surveys?

Choose the single 384x288, 13 mm, 25 Hz Android model; its 17 µm pixels and 8–14 µm spectral band suit both close-up board work and wider floor scans.
