Compact thermal camera module with matte black finish and lens housing, designed to plug into iPhone 15 series

InfiRay

InfiRay T2L Thermal Imager for iPhone 15 Series

SKU CH-7PX5-AMJ7S

A 256×192 thermal imager with 12 µm pixels, 25 Hz frame rate and 8 mm macro focus plugs into iPhone 15 series for PCB fault finding and night vision

  • TypeThermal Imager
  • Spot PCB faults at 8 mm macro distance
  • 256 × 192 thermal resolution reveals fine detail
  • 25 Hz frame rate gives smooth live view
  • Measure –20 °C to 120 °C with ±3 °C accuracy
  • Works with iPhone 15 series and Android via app

PCB fault finding tool for iPhone 15

The InfiRay T2L plugs directly into the iPhone 15 series Lightning port and turns the phone into a 256x192 thermal imager. Its 12 µm pixel pitch and 8 mm macro focus let technicians spot component-level hot spots on circuit boards. The 44.9°×33.4° field of view covers a useful area at close range while the 25 Hz frame rate keeps motion smooth during probing.

Upgrade from handheld spot thermometers

A single-point IR thermometer only shows one temperature at a time; this imager reveals the full thermal map so shorts, open traces and overloaded regulators appear instantly. The jump is worth it when intermittent faults need visual confirmation across a whole board rather than repeated single-spot checks. Measurement accuracy of ±3 °C or ±3 % of range supports quantitative comparison before and after rework.

Sustained inspection sessions

Operating temperature spans -20 °C to +50 °C so the unit stays functional in cold workshops or warm enclosures. Manual and automatic image correction counters drift during long captures while digital detail enhancement preserves contrast without external processing. The SDK allows automated logging scripts to run for extended periods and the app stores both photos and video locally for later analysis.

Highlights

  • Spot PCB faults at 8 mm macro distance
  • 256 × 192 thermal resolution reveals fine detail
  • 25 Hz frame rate gives smooth live view
  • Measure –20 °C to 120 °C with ±3 °C accuracy
  • Works with iPhone 15 series and Android via app

Specifications

TypeThermal Imager

Questions about this item

Will the 26 × 26 × 24.2 mm body clear the camera bump on my iPhone 15 Pro Max?

The imager measures 26 × 26 × 24.2 mm and plugs directly into the iPhone 15 series Lightning/USB-C port; it adds roughly 24 mm of depth beyond the port face, so most slim cases must be removed for a solid connection.

Do I need to install a driver or grant camera permission before the first thermal image appears?

Install the InfiRay iOS app from the App Store, plug the T2L into the iPhone 15 port, then allow the app access to the camera and local network when prompted; the sensor streams at 25 Hz once permission is granted.

How often should I run the manual flat-field correction using the built-in shutter?

Run manual correction whenever the scene temperature shifts by more than 10 °C or after the device has been powered on for 15 minutes; the app also offers automatic correction that triggers based on internal temperature drift.
