Compact thermal camera with Lightning connector, matte grey finish, 26 by 26 by 24.2 mm

InfiRay

InfiRay T2L Thermal Imager 256x192 12µm 25Hz iOS

SKU CH-W40Y-2K7BY

Thermal imager with 256x192 resolution, 12µm pixels, 25Hz frame rate and 8mm macro lens for iOS devices

  • TypeThermal Imager
  • Spot PCB faults up close with 8 mm macro focus
  • 256 × 192 resolution at 12 µm pitch for detailed thermal images
  • Smooth 25 Hz frame rate keeps live view fluid
  • Measure from –20 °C to 120 °C with ±3 °C or ±3 % accuracy
  • iOS and Android app adds palettes, stats, photo and video storage

PCB fault finding with 256x192 thermal sensor

The InfiRay T2L thermal imager connects to iOS devices through the Lightning interface and delivers a 256 by 192 pixel image at 25 Hz. A 12 µm pixel pitch and a 44.9° by 33.4° field of view suit close-range inspection of circuit boards and electrical components. Measurement range spans -20 °C to +120 °C with stated accuracy of ±3 °C or ±3 % of reading.

Plug into Lightning port and launch the app

Installation requires an iOS device with a Lightning connector; the iPhone 15 series uses USB-C and needs a separate adapter that is not included. The companion app handles manual or automatic image correction, palette selection and on-screen temperature statistics. Common issues arise when users expect direct USB-C compatibility or overlook the need for the extra adapter on newer iPhones.

Steady 25 Hz frame rate during extended scans

The imager maintains its 25 Hz refresh rate while powered from the host phone, and the operating temperature window of -20 °C to +50 °C covers typical indoor and outdoor sessions. Power draw is low enough for prolonged use without overheating the module. Photo and video capture run continuously, and the SDK allows custom integration for automated logging.

Highlights

  • Spot PCB faults up close with 8 mm macro focus
  • 256 × 192 resolution at 12 µm pitch for detailed thermal images
  • Smooth 25 Hz frame rate keeps live view fluid
  • Measure from –20 °C to 120 °C with ±3 °C or ±3 % accuracy
  • iOS and Android app adds palettes, stats, photo and video storage

Specifications

TypeThermal Imager

Questions about this item

How can I confirm the T2L is measuring temperatures correctly after connecting it to my iPhone?

Point the 8 mm macro lens at a known heat source and check that the app shows a reading within ±3 °C or ±3 % of the expected value across the -20 °C to +120 °C range.

What comes in the box with the T2L and what must I buy separately to use it with an iPhone 15?

The thermal imager itself is included; a Lightning-to-USB-C adapter or the specific iPhone 15 connection accessory must be purchased separately.

Which T2L specification should I compare when deciding between this model and other thermal imagers?

Compare the 256 × 192 resolution, 12 µm pixel pitch, 25 Hz frame rate and 44.9 ° × 33.4 ° field of view against your inspection requirements.
