Blue bulk Ethernet cable reel, 1000 ft riser-rated shielded Cat6a

Infinity Cable Products

Infinity Cable Products Elite Cat6a Shielded Riser 1000ft 650MHz 23AWG Blue video accessory

SKU CH-XJDP-T11WQ

Shielded Cat6a riser cable runs 1000 ft, supports 10 Gbps at 650 MHz over 328 ft, uses 23 AWG solid copper with foil shield and drain wire, CMR rated for in-wall use, UL listed and TAA compliant

  • TypeEthernet
  • Length1000 ft.
  • ColorBlue
  • ConnectorsRJ45s and Keystone Jacks
  • Specifications23AWG
  • Weight49 lbs
  • Supports 10Gb Ethernet up to 328 feet
  • 650 MHz bandwidth exceeds 568.2-D standard by 3 to 5 dB
  • CMR riser rating allows in-wall and between-floor runs
  • 23 AWG solid pure copper conductors with overall foil shield
  • UL listed, LP certified, ETL verified, RoHS and TAA compliant

1000 ft Cat6a Shielded Riser

This bulk Ethernet cable is a CMR-rated F/UTP reel with an overall foil shield and drain wire. It uses 23 AWG solid bare copper conductors and a spline separator to support 10 Gigabit speeds up to 328 feet. The jacket is printed with specifications and UL markings for easy identification during installation.

Suited for in-wall and riser runs

The riser rating makes it appropriate for vertical shafts, between floors and general commercial or residential structured wiring. Buyers who need a plenum-rated jacket for air-handling spaces should look at a different cable type. The shielded design helps in environments with electromagnetic interference but adds termination steps compared with unshielded alternatives.

650 MHz bandwidth under sustained load

The construction delivers 3 to 5 dB margin above the 568.2 standard, maintaining signal integrity on long 10GBASE-T links. Solid copper conductors reduce attenuation and heat rise during continuous Power over Ethernet use. The foil shield and drain wire contain alien crosstalk when multiple cables are bundled tightly in pathways.

Highlights

  • Supports 10Gb Ethernet up to 328 feet
  • 650 MHz bandwidth exceeds 568.2-D standard by 3 to 5 dB
  • CMR riser rating allows in-wall and between-floor runs
  • 23 AWG solid pure copper conductors with overall foil shield
  • UL listed, LP certified, ETL verified, RoHS and TAA compliant

Specifications

BrandElite
ModelCat6a Shielded Riser
TypeEthernet
Length1000 ft.
ColorBlue
ConnectorsRJ45s and Keystone Jacks
Specifications23AWG
Weight49 lbs

Questions about this item

What connectors must I already have to terminate this 23AWG F/UTP cable?

You need RJ45 plugs or keystone jacks rated for Cat6a shielded cable and a compatible crimp or punch-down tool for 23AWG solid conductors.

Can I run this CMR cable alongside older Cat5e patch cords in the same pathway?

Yes, the foil shield and drain wire protect the 650MHz signals from alien crosstalk when bundled with legacy unshielded cables.

How do I verify the reel delivers the printed 10Gb performance after installation?

Run a Cat6a-certified field tester; it should show 3–5 dB margin above the TIA-568.2-D limit across all four pairs up to 328 ft.
