Blue Cat6 riser cable in 1000ft Reelex II pull box

Infinity Cable Products

Infinity Cable Products Cat6 Riser CMR 1000ft Blue 23AWG 550MHz 2 in 1 accessory

SKU CH-6935-Z7PZ5

Blue Cat6 riser cable delivers 550 MHz bandwidth over 1000 feet of solid copper for Gigabit Ethernet and PoE runs

  • Cat6 Riser CMR rating supports safe in-wall and between-floor installs
  • 23AWG solid bare copper conductors deliver 3-5 dB margin above TIA-568.2-D
  • No spline design with extra pair insulation reduces near-end crosstalk
  • 550MHz bandwidth enables 1Gb Ethernet up to 328 feet
  • 1000ft Reelex II box allows easy pulling and is 100% recyclable

Blue Cat6 Riser Cable for LAN Installations

This 1000ft bulk Cat6 riser cable is built for permanent network runs in walls and between floors. It uses solid bare copper conductors and an unshielded twisted-pair design rated CMR for non-plenum spaces. The blue jacket helps identify links in structured cabling projects. It suits installers and IT teams wiring homes, offices or campus backbones.

550 MHz Bandwidth with 3–5 dB Margin Over Standard

The cable is specified to 550 MHz and tested with a Fluke DSX-8000 Versiv Cable Analyzer to exceed EIA/TIA-568.2-D by 3–5 dB. It supports 1 Gb Ethernet at the full 328 ft channel length and can reach 10 Gb at shorter distances. The 23 AWG solid conductors and extra pair insulation reduce near-end crosstalk without a centre spline.

No-Spline Design for Flexible Pulls in Reelex II Box

The spline-free construction makes the cable easier to bend and route through tight stud bays and conduit. It terminates with standard unshielded Cat6 keystone jacks, RJ45 plugs or field-termination plugs. The Reelex II payout box dispenses smoothly without tangling and is fully recyclable. PoE and PoE+ are supported for powered devices along the run.

Highlights

  • Cat6 Riser CMR rating supports safe in-wall and between-floor installs
  • 23AWG solid bare copper conductors deliver 3-5 dB margin above TIA-568.2-D
  • No spline design with extra pair insulation reduces near-end crosstalk
  • 550MHz bandwidth enables 1Gb Ethernet up to 328 feet
  • 1000ft Reelex II box allows easy pulling and is 100% recyclable

Specifications

No published specifications for this item yet.

Questions about this item

What does the 550 MHz rating mean for actual network speeds?

The cable is tested to 550 MHz and supports 1 Gb Ethernet at the full 328 ft (100 m) channel length. It can reach 10 Gb Ethernet at shorter distances.

How does the CMR riser rating limit where I can install this cable?

CMR is approved for vertical riser runs and in-wall or between-floor installations in non-plenum spaces. It can also be used wherever a CM rating is required.

What physical space and tools are needed to pull and mount the 1000 ft reel?

The Reelex II box pays out smoothly without tangling and fits through standard stud bays. The 23 AWG solid copper conductors terminate on standard Cat6 keystones, RJ45 plugs and field-termination plugs.
