IHDAPP
IHDAPP 404DH KVM Switch 4×4 8K30 4K120 HDMI+3DP USB 3.0 Wired Remote
Share one keyboard, mouse and four USB 3.0 devices across four computers on four monitors at up to 8K 30 Hz or 4K 120 Hz with wired remote switching
- TypeHDMI +3 Displayport Quad Monitor KVM switch
- Computer Connections4 Ports
- Monitor Connections4 Ports
- Video ResolutionQuad monitor KVM switch 4 port supports up to 8K@30Hz/4K@120
- PC SelectionPush Buttons
- Monitors SupportedHDMI, DP, DP, DP
- Control four computers with one keyboard and mouse set
- Share four monitors across systems in extended or mirrored modes
- USB 3.0 hub delivers 5 Gbps data transfer for peripherals
- Supports 8K at 30 Hz and 4K at 120 Hz resolution
- Wired remote and front buttons give instant PC switching
Quad-monitor KVM for four desktops
This KVM switch connects four desktop computers to four monitors using one HDMI and three DisplayPort outputs per system. It is built for users who need a single keyboard, mouse and USB hub to control multiple workstations without unplugging cables. Laptops and docking stations are not supported because they cannot drive four native video ports.
Requires GPU with three DP and one HDMI
Each computer must provide three native DisplayPort connectors and one native HDMI connector to feed the four monitor inputs. The unit does not perform matrix switching; output A always shows input A. Adapters or converters will break the signal path, so only direct cables to the graphics card ports will work.
Four USB 3.0 ports and TF card slot at 5 Gbps
The integrated hub adds four USB 3.0 ports and a TF card reader that transfer data at 5 Gbps, ten times the speed of USB 2.0. A wired remote and front-panel buttons both switch the active computer, while the included 12 V power adapter keeps the hub and video circuitry stable. Audio and microphone pass-through are also provided.
Highlights
- Control four computers with one keyboard and mouse set
- Share four monitors across systems in extended or mirrored modes
- USB 3.0 hub delivers 5 Gbps data transfer for peripherals
- Supports 8K at 30 Hz and 4K at 120 Hz resolution
- Wired remote and front buttons give instant PC switching
Specifications
| Model | 404DH |
|---|---|
| Type | HDMI +3 Displayport Quad Monitor KVM switch |
| Computer Connections | 4 Ports |
| Monitor Connections | 4 Ports |
| Video Resolution | Quad monitor KVM switch 4 port supports up to 8K@30Hz/4K@120Hz, (Warming: Please use HDMI2.1 and DP1.4 cables for a better experience, shoif the set distance allows,the length of cables more short more better.)This product requires a dedicated graphics card with 3 DP inputs and 1 HDMI output. |
| PC Selection | Push Buttons |
| Monitors Supported | HDMI, DP, DP, DP |
| LED Indicators | Yes |
| Audio Features | with Audio |
| Power Features | Come with Dc 12V Power Adapter |
| USB Features | HDMI+ 3*Displayport KVM Switch integrated 4 USB 3.0 ports and TF card for keyboard, mouse, printer & USB drives – supports 5Gbps ultra-high-speed data transfer (10x faster than USB 2.0). |
| Application | This KVM switch 4 monitors 4 computers can control 4 or 3 computers(Destop) with 1 independent set of keyboard and mouse to share 4/3 monitors and 4 USB 3.0 hub.(supports extended and mirrored display modes) |
| Features | with 4 USB 3.0 Ports+TF card |
| Dimensions | 3.94 x 2.76 x 0.79 inches |
| Package Contents | 1* Quad Monitor KVM Switch, 4* USB 3.0 Cable, 1* Power Adapter, 1* Wired Remote, 1* User's Manual. |
Questions about this item
What does the 8K@30Hz / 4K@120Hz rating mean once the switch is connected to a real desktop?
Each of the four monitor outputs can display up to 8K at 30 Hz or 4K at 120 Hz, provided the host graphics card has three native DisplayPort 1.4 outputs and one native HDMI 2.1 output and you use matching cables.
How does the HDMI 2.1 and DisplayPort 1.4 interface limit what I can actually run?
The switch passes HDMI 2.1 and DP 1.4 signals natively; it will not convert or upscale, so the host GPU must supply those exact interfaces and the cable length should be kept short for reliable 8K30 or 4K120 operation.
What physical space and connections does the 404DH need to fit and mount?
The unit measures 3.94 x 2.76 x .79 inches and requires four USB 3.0 host cables, one HDMI and three DisplayPort video cables per computer, plus the included 12 V DC power adapter and wired remote.
